Help CenterBMD703-400 Cnc Drill Machine Price
Related Products
-
High Quality Drilling EDM BMD703-500US$ 1.333 - 8,697,597MOQ: 1 Set -
BMD703-500CNC/2015 New Cnc Edm Hole Drilling Machine/drill Edm/Lower Price/High Performance/High QualityUS$ 0.00001 - 20,000MOQ: 1 Set
-
Highly Active and Accuracy Wire EDM Spark Drill Machine BMD703-400/drill Edm/edm Drilling MachineUS$ 0.00001 - 20,000MOQ: 1 Set
-
Highly Active and Accuracy Wire EDM Spark Drill Machine BMD703-500/drill Edm/edm Small Hole Drilling MachineUS$ 0.00001 - 20,000MOQ: 1 Set
-
Drilling Machine BMD703-500ZNCUS$ 0.1 - 20,000MOQ: 1 Set
Specifications
Re track speed 2 times quicker than DB703Can drill various conductive metals
Hole Size 0.2mm--3.0mm
Drill Speed 30-60mm2/min
Product Description
Main Function
A. There is a window on the machine bed for pump pressure, which is easy and convenient to look and adapt water pressure.
B. Servo control system is adopted and improved, which make drilling re-track speed 2 times quicker than dB703
C. There is slider water tank, which saves space and is more environmental.
D. There is oil-tank for lubrication, which is more convenient to operate and fluid to lubricate.
E. Able to drill various conductive metals, such as stainless steel, chilly steel, solid carbide, copper, aluminum etc.
F. Able to drill holes range from diameter 0.2- 3mm with max depth-diameter ration 300: 1.
G. It is more stable while drilling hole of 0.2mm
H. Drilling speed 30-60mm/min
I. Able to drill directly into bevel or curve surface.
J. Three axis digital display
K. Drilling depth positioning function for Z axis
L. Control system can drill group hole and positioning automatically.
Item |
BMD703-400 |
Worktable size(L×W)mm |
486×310 |
Table travel(X×Y)mm |
400×300 |
Z axis travel mm |
300+(320) |
Max. drilling depth mm |
0-300 |
Max. drilling speed mm2/min |
60 |
Max re-track speed of spindle mm/min |
320 |
Max. working current A |
30 |
Electrode diameter |
0.2-3.0 |
Load of table kg |
300 |
Working solution |
Water/Saponification |
Working reservoir capacity L |
30 |
Power supply |
380V AC/50 Hz or 415V AC/50 Hz |
Max. Power consumption KVA |
3.5 |
Machine dimension mm |
1236×1025mm×1934 |
Package dimension mm |
1400×1450×2050 |
Machine weight kg |
700 |
Controller type |
Automatic Z axis |
Digital Display |
X,Y,Z axis |
Function of setting depth |
yes |
Function of group drilling |
yes |
