2g11 Led Tube 22w Single End Base

Name: 2g11 Led Tube 22w Single End Base
Brand: GENICE
SKU: 106968823
Availability: InStock

US$ 15 - 18 MOQ: 100 Pieces

Key Specifications

LED Light Source:

Epistar 2835/168PCS

Warranty(Years):

Input Voltage(V):

AC100-277V

Shenzhen Genice Lighting Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source Epistar 2835/168PCS

Warranty(Years) 3

Input Voltage(V) AC100-277V

Lamp Power(W) 18

Lamp Luminous Flux(lm) 1800-2000

Lamp Luminous Efficiency(lm/w) 100

Color Temperature(CCT) Other, 2700-6500K optional

Working Temperature(℃) -20, 50

Working Lifetime(Hour) 35000

Lamp Body Material Other, Aluminum+PC

IP Rating Other, IP40

Certification BV, CE, EMC, LVD, UL

Place of Origin Guangdong, China

Brand Name GENICE

Model Number Other, GE-G1118S

Specifications

2g11 led tube 22w Single End Base
1 18w, 542mm
2. AC100-277V 50/60HZ
2 CE&ROHS
3 35,000h

2g11 led tube 22w Single End Base

	Model	GE-G1118S-FR	GE-G1118S-CL
A. Electrical Parameters
1	Input Voltage	AC100-277V	AC100-277V
2	Power Consumption	18W	18W
3	Frequency Range	50/60Hz	50/60Hz
4	Pow Factor	> 0.95	> 0.95
5	Power Efficiency	> 85%	> 85%
B. Optical Parameters
7	Luminous Flux	1800Lumens	2000Lumens
8	LED Luminous Efficiency	90-100Lm/W	100-110Lm/W
9	Lamp's Efficiency	>90%	> 90%
10	Color Temperature	(2700-3300K)/(4000-4500k)/(5500-6500K)	(2700-3300K)/(4000-4500k)/(5500-6500K)
11	CRI(Ra)	> 80	>80
12	Viewing Angle	120°	120°
C. Other Parameters
13	Lamp Holder/Base	2G11	2G11
14	Dimension	L542mm	L542mm
15	Housing material	PC + Aluminum	PC + Aluminum
16	N.W.	321g	321g
17	Chip Brand/Light Source	Epistar	Epistar
18	LED Quantity	168pcs SMD 2835LEDs	168pcs SMD 2835LEDs
19	Life time	>35,000hours	>35,000hours
20	Warranty	3Years	3Years
21	Certificates	CE/ROHS approved, UL pending	CE/ROHS approved, UL pending
D. Energy Saving and Low carbon
22	Replacement	26W traditional 2g11 Fluorescent tube	26W traditional 2g11 Fluorescent tube
E. Working Environment
23	Working Temperature	-20°C~50°C	-20°C~50°C
24	Working Humidity	10~90%	10~90%
