hakko FG-101 tester

Specifications

hakko FG 101 soldering tester
One tester for all your daily soldering iron maintenance needs

Maximun current value mesured with HAKKO FG-101
100V-120V Spec 5A
220V-240V Spec  3A

Note: HAKKO FG-101 is broken when beyond maximum current value is measured.

  In addition to traditional features, the FG-101 comes with two new functions: MAX HOLD and AUTO ZERO.
 MAX HOLD Function Constantly displays the maximum temperature
AUTOZERO Function Automatically corrects zero point error of measuring instruments
Traditional Features Lead-free sensor
Measures leak voltage by True Root Mean Square (TRMS)
Highly reliable - Resistant to drift and changes in temperature
* The FG-101 does not come with the Monitor Output function that was included in past models.



 MAX HOLD Function
When the MAX HOLD function is on, the maximum temperature is constantly displayed on the LCD.
If the MAX HOLD button is pressed for a short time (less than 1 second) the maximum temperature is updated. If the button is pressed for a long time (1 second or longer) the MAX HOLD function turns off.





 AUTO ZERO Function
The zero point error of measuring instruments can be corrected by simply pressing the AUTO ZERO button and waiting for the display to return to normal.
