A.With a top cover on the platform for access to the load cells.
B.Composed of 4 or 6 U beams and C channel beams,robust and rigid.
C.Middle dissected,with bolts connection. Double shear beam load cell or compression load cell selectable.
E.Pit & pitless mounted alternatively,and pit mounted more often. F.Easy assembly and installation
Width available:3m,3.2m,3.4m. Standard length available:6m,7m,8m,9m,10m,12m,14m,16m,18m,20m,21m,24m.
Max Capacity available:30t,40t,60t,80t,100t,120t. 3 sets of 3x18m can be placed in one 40'high container
Customer visit factory and check ordered truck scale
Emily take photos with her customers
Paramater of electronic weight scale
Accuracy grade: OIML III Weighing Range: 20~120t
Length of Weighing Platform: 6~24m
Signal transmission distance: 1200meter
Working temperature: Indicator -10degree~+60degree
Load Cell -30degree~+70degree Safe overload: 130%
1.What's technological process of electronic weight scale manufacturing?
Blanking---Fold U shaped beam---U shaped beam pre-arch---U shaped beam automatic welding---Install and weld end plate---Surface shot blasting treatment---Surface protection treatment (epoxy zinc rich primer, acrylic polyurethane coating) ---Full scale calibration
2.What's the electronic weight scale parameter??
Steel material: Q235 high quality durable steel
Truck scale structure: U beamTop plate: 8mm checker plate, 10mm, 12mm flat plate
U beam thickness:6mm U beam height:300mm Connection plate:40mm
3. How to Install the electronic weight scale ?
We will send the installation manual and installation vedio to your side, it is easy to install the truck scale.
4. How about the delivery time, payment term, warranty time?
Delivery time: in general 15 days, if you are our distributor we can stock some sets truck scale for your side
Payment term: 30% deposit, 70% balance by TT, LC, Payal,
Warranty time: 3 years
