EV- Charger

US$ 400 - 6,000 MOQ: 10 Sets

Key Specifications

Place of Origin:

China

Brand Name:

BOS

Shandong BOS Energy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name BOS

charger	charging pile with gun	charging pile with socket
charge interface type	charging gun	socket
cable Length	L, N, and ground wire (5 m)	no
input voltage	230VAC,single phase
input current	30A/16a
operating frequency	60HZ/50HZ
standby power consumption	<4W
measuring accuracy	≤1%
output voltage	230VAC,single phase
output current	30A/16A
maximum power	7.2KW/3.6KW
cold start	start before delay and after power failure
circuit breaker	each charging gun and charging socket has a separate leakage protection circuit breaker which is 40A has shunt tripping device;residual current protection rated current is 20mA,the actuation time≤0.1s
protection	o vervoltage, undervoltage, overcurrent, short circuit, overheating, lightning surges, ground fault protection
socket protection	connecting protection when not charging
creepage distance	6mm
emergency stop	E-stop button cut off charging.Unplugged in the charging state and it will immediately cut off the power
button switchs	on/off button,stop button,delay button
user authentication	RFID, Mifare card way for user authentication and follows the ISO14443 TypeA, ISO14443 TypeB agreement;J1772
timing charging	charging time can be set
status indicators	standby(green),charging(flashing green),fault(red),waring(flashing red)
network interface	GPRS,WI-FI,3G,ethernet
operating temperature	-30°C-75°C
humidity	95% relative humidity,non-condensing
ingress protection	NEMA4X
cooling	natural cooling
net weight	7KG
