Polyethylene Electric Heating Fusion Tape

Specifications

Polyethylene Electric Heating Fusion Tape
1.Tensile strength:15.0Mpa
2. Good anticorrosion
3. No PU leak
4. Aging resistant

Polyethylene Electric Heating Fusion Tape



It is a kind of special-purpose pipe connection, which is made by embedding specific electric heating melt welding wire in the basis of high quality PE sheet with special technicals.

Mainly used for Oil&thermal pipeline, such as Pre-insulated Pipes.



Performance characteristic:



good bonding strength, excellent seal, high air-tightness, no PU leak, corrosion resistant, aging resistant, and easy to operate. Electric hot melt sleeve is an emerging connect fitting in anti-corrosion and thermal insulating industries. Its largely outperforms heat-shrinkable strip in terms of aging-resistance, bonding strength, and ring stiffness, further more, it applies PU foam after melting the jacketed pipes, this process needs much less time than using a heat-shrinkable strip; therefore, electric hot melting sleeves are widely welcomed in joint coating and connecting of heat distribution pipeline and oil pipeline.



 Features & Benefits:

• Waterproof; good sealing capacity;
• Able to withstand axial forces initiated by axial moments of the pipe in the ground;
• Able to withstand radial forces and bending forces; high tensil strength;
• Able to withstand effects of temperature and temperature variatations.
• Have the same thickness of the pipeline insulation layer.
• Could be used as drawing pipe  scope of application: DN200~DN3000mm

Testing program	Required technical	Testing result	Testing method
Appearance	The appearance of  HDPE electric fusion sleeve is smooth and flat, no bubble, no split, no discolor because of decomposition; and the embessed fusion net is no disconnect and tilting.	pass	Tested by eye under the sunlight.
Tensile strength	≥13Mpa	15.0Mpa	GB/T 8804.3-2003
Hydraulic pressure test	20°C,0.1Mpa water pressure, no damage and leakage after 1 hour	pass	GB/T 6111-2003
Air leakage test	20°C,0.1Mpa air pressure,no damage and leakage after 1 hour	Pass	GB/T 6111-2003
