Help CenterHeat Shrinkable Sleeve for Oil Pipeline
Related Products
Specifications
Heat Shrinkable Sleeve1. Field Coating Materials
2. Offeshore &Underground
3. Oil, Gas,Water pipeline
4. DN105-1500
Heat Shrinkable Sleeve
1.1 Product Structure
- The inner layer is two-components epoxy primer which coated on steel pipe;
- Intermediate level is special hot melt adhesive;
- Outer layer is modified radiation crossing linking polyethylene backing.
1.2 Features & Benefits:
Heat Shrinkable Sleeves provide great corrosion protection, Superior resistance to Cathodic Disbondment and excellent durability against abrasion and chemical attack. The result is effective, good performance of sealing, wide application, easy to operate and preheating temperature low (50 °C) ,long term protection against corrosion.
- Cross-linked backing provides superior abrasion, mechanical and chemical attack resistance.
- High performance adhesive provides excellent resistance to Cathodic Disbondment to ensure long-term corrosion protection.
- Just-in-time customized lengths allow bulk rolls to be field cut to protect any pipe size
- Open sleeve configuration allows the product to be applied after the pipeline has been welded and cleaned.
1.3 Specification( mm)
Pipeline size: from Ø 108 to Ø 1554 ( 4’’---60’’)
Sleeves width: 100mm, 150mm,200mm, 300mm,450mm,500mm,600mm,900mm
Closure patch: 100mm, 150mm,200mm (4’’, 6’’, 8’’)
Model: HSS 3600/505/ Ø 1066.8
HSS--Heat shrinkable sleeves
3600------Roll length(mm)
505----- -Roll Width (as supplied)
Ø 1066.8----Joint or pipeline Diameter
1.4 Technical Datas
