IP65 stainless steel metal kiosk desk keyboard

FOB Price

USD $100 - $100 / Piece

1 Piece(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port shenzhen
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	DSP	Model Number:	D8003
Application:	Other, Kiosk	Keypad Button Material:	Metal

Product Description

High quality stainless steel metal kiosk keyboard

APPLICATION

· This keyboards is constructed to survive in exposed, unsupervised, public environments, and military as Army, Navy, Air force.

· Their responsive key action ensures rapid, reliable and responsive data entry in tough, wet or hostile conditions. A hardened stainless steel front plate and polymer keys ensure the keyboards resistance to hard use, abuse and vandalism. A water and impact resistant trackball makes this keyboard the complete and ideal solution for PC data entry in menu based point & click application.

MAIN FEATURE

· Vandal resistant

· Keyboard with NVIS-compliant red adjustable backlighting, while NVIS backlighting makes this keyboard ideal for military, aviation or vehicle applications where night vision goggles are necessary.

· Polymer keys ensure the keyboards resistance to willful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.

· Waterproof execution according to degree of protection IP65 from the panel, the keyboard is sealed against the ingress or liquid and dirt.

· The keyboards have an excellent tactile feel with full-long travel switches and allow users to achieve fast and accurate data input without any noise. With firm tactile perception for comfortable operation

· Internet friendly key layout, key-tops are laser-etched or high quality ink print in legends and characters for easy readability, long life to prevent lettering rub-off.

· RFI / EMI Protection in accordance with current European and U.S. directives.

· Ease of customizing with multiple languages, to accommodate foreign or custom variants.

· Desktop solution, and is provided with PS/2, USB connection output cables that plug directly into the host computer for normal keyboard operations.

· Operational life of more than 10 million cycles per key.

· Resistant to most commonly used cleaning agents.

MECHANICAL DATA

· Key top style: Protuberant rectangular keys.

· Key travel: 2.0mm

· Switch life: more than 10 million of operations.

· Lettering: laser-etched or high quality ink print.

· Actuator/keys materials: polymer

ELECTRICAL DATA

· Supply Voltage: +5V DC +/-5%

· Current Rating: appr. 30mA

· EMC Standard: It is compliance with the council EMC directive 89/336/EEC EN55022:1988+A1:2000+A2:2003 EN55024: 1988+A1:2001+A2:2003

· Emission: EN 50081-1

· Immunity: EN 50082-1

· Lifespan>5 years

· Switch Contact Material: Carbon-on-Gold key switch technology PCB.

· Interface: PS2, USB available.

· OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/win7/win8/win9/win10, Linux, Unix, Mac OSX

ENVIRONMENTAL ADAPTABILITY

· Operating temperature:-20oC to +60oC

· Storage temperature: -30oC to +70oC

· Operating RH: 30-90%

· Atmospheric pressure: 60-106Kpa.

· Saline mist: 96 hours, IEC 60512-6

· Damp heat test at + 40oC: 21 days, IEC 60512-6

· Dry heat test at + 85oC: 10 days, IEC 60512-6

RELIABILITY

· RoHS Compliant, CE and FCC,ESD

· Protection Level: IP65(front panel)

· Vandal resistant IK10

· Key Lifespan >10 million actuations

· MTBF >50000H

· MTTR <30min
