SFB series large size screen printing machine apply to wide range of packaging industry.large size screen printing machine 1 Professional manufacturer of making screen printer.
2 Many years experience in export.
3 Can produce any special size printer to meet your requirement.
DESCRIPTION
SFB series apply to wide range of packaging industry, such as box decorating fields for makeup, wine, gift, calendar adhesives, and even credit cards etc. It features AC motor-driven printing and lift-up/lift-down for the print arm, speed adjusted b high precision frequency converter. Most importantly, the combination of squeegee and flood bar speed and substrate thickness adjustment can be incorporated into one machine. In addition, the pallet allows for up-and-down, left-and-right, front-and-back tuning to the superior registration. It is also equipped with the excellent safety system when printing.
FEATURES
1, Microcomputer fault with that plan, facilitates future maintenance machines.
2, Four-cylinder printing, printing effect to the average pressure, a clear line network.
3, A two-state adaptive systems, adjustment is simple, accurate positioning.
4, A printing, printing ink and to be independent governor can adapt to a variety of printing plane.
5, Crank-driven printing itinerary.
TECHNICAL PARAMTERS
MODEL | SFB-8060 | SFB-9060 | SFB-12060 | SFB-12080 |
MAX.PRINTIGN SIZE | 800x600mm | 900x600mm | 1200x600mm | 1200x800mm |
WORKTABLE SIZE | 900x800mm | 1000x800mm | 1300x800mm | 1300x1000mm |
MAX.FRAME SIZE | 1000x850mm | 1100x850mm | 1400x850mm | 1400x1100mm |
AIR PRESSURE | 0.4-0.6mpa | 0.4-0.6mpa | 0.4-0.6mpa | 0.4-0.6mpa |
MAX.PRINTING SPEED | 1200t/h | 1200t/h | 1100t/h | 1000t/h |
POWER | 2.2kw | 2.2kw | 3.2kw | 3.2kw |
WEIGHT | 550kg | 580kg | 620kg | 800kg |
MACHINE SIZE | 1570x1080x1450mm | 1570x1080x1450mm | 1570x1380x1450mm | 1850x1380x1450mm |
