Customized Thermoplastic Large Car Top Roof Box Quality Choice

Welcom to Shenzhen Amei Brothers Co.Ltd

Home

customized thermoplastic large  car  top roof box

                    high quality,strong,durable,eco-friendly,UV/UL-resistant
                                     outdoor ,dual opening
                               OEM &ODM is acceptable
                             ABS box,steel base trestle

                                  logo painting are available
professional engineer, expertly in CAD, UG, Pro-E and Solidworks for mould making

1.Material:   ABS

2.Color:Customlized

3.Thickness:1-12mm

4.Size:  Customlized

5.Brand name:  Amei

6.Processing: Vacuum forming +CNC Cutting +scraping

7.Feature:Durable ,hard

8.Packing:We can meet the customer's requirements

9.Description: Large OEM Design  Thermoforming  Plastic manufacturer

10Design: OEM/ODM

11.Business type: Manufacture

12.Certificate: SO9001:2000

13.Sample: 10-15 days for making the mould and finished the sample

14.Lead time: 15-30 days for finishing the goods

15.Main market:USA, EUROPE , UK ,AUSTRALIA,GERMANY...

16.Employees:50-100 workers

18.Equipment:8 sets of vacuum thermoforming machines+6sets of CNC machines and other machines.

our advantage:

1.We have many years of experiences in this area

 2.Large-scale produce line, quick delivery

 3.Short time for mold and samples

 4.Supporting deep-processing

 5.High quality materials

1.Extruding plastic sheet:

ABS, HIPS, PP, PE, PC, PETG, PMMA resin granules are extruded or co-extruded into thermoplastic sheet--textured, smooth, gloss or matt, fire-retarded or UV resisted

2.Vacuum forming to shape:

After being heated, the plastic sheet is stretched onto or into a mould, and held against the mold by applying vacuum between the mould surface and the sheet to form desired shapes.

3.Cooling to maintain shape:

Once formed the plastic need to cool before being released from the mould. To speed up the cooling cycle, fans are fitted and activated once the plastic part is formed.

4.Making large product:

Our machine could be restructured to make larger plastic ABS thick vacuum forming plastic shell, with maximun dimensions of 3000*2000*800* (L*W*H*T)

5.Trimming edges:

Extra material is firstly trimmed before more accurate processing. Sawing is often used in this stages. Polishing is made additioanlly to smoothen the edges.

6.Drilling holes:

Drilling oftens follow the trimming. Other post forming processes include decoration, printing, strengthening, reinforcing and assembly.

7.CNC Processing:

For more accurate and faster speed post thick ABS vacuum forming plastic shell processing, CNC is often used. The machine is computer programmed to select the correct cutting tools and angle to suit each cutting area.

8.Examination and checking:

Before packaging, all our thick vacuum forming samples and products will be carefully checked in terms of dimensions, surface finish, stenghth, colour requirements and so on.

9.Cleansing and Packaging

All ABS thick vacuum forming plastic shells are cleaned before packaging. Products are wrapped with plastic film to prevent scratches and cartoon boxs are used or other methods are applied as required.

We can do the  maximum  size is 3000*2000*800mm.The thickness can reach 12mm.The materials include PMMA,ABS,PP,PE,PET,PETG,etc.

We can produce products  according to your design.If you have any pictures or designs, pls send it to us.It would be appreciated if you could provide us 3D drawings.

• We are able to do silkscreen, plating, spraying.
• We can add your own logo. we are largest manufacturer of vacuum forming products as customer design in Shenzhen,
• We have our own experienced mould technicians and CNC mould machines.
• We have adopted vacuum thermoforming method in order to minimize the product development cost for customers; we provide one stop service including mould design.

  If you have your own design,pls tell us the information as follows:

1.The material you can  choose:  ABS ,PMMA,PE,PP,PET,PETG,HIPS,PVC, or PC.

2.The thickness of the material:1-10mm are acceptable ,you can choose within this range

3.The specifications of the product (L*W*H)

4.The color of the material (if you have your own logo ,pls tell us how many colors the logo includes)

5.Pls also tell us the quantity you want to order(of course,it must surpass our MOQ)

6.It would be appreciated if you could provide us 3D drawings.If you don't have 3D drawings,pls send your 2D drawings and actual picture to us.Thanks !

1.Minimun Order Quantity: 500pcs per order

2.Payment Terms: T/T

3.Payment: 50% T/T , the balance before shipment

4.Port:Shenzhen

5.Packaging Details: standard export carton, or accoding to  customer's requirements

.
6.Delivery Time: Within 7-20 work days after receipt of the deposit
