Specifications
ABS vacuum thermoforming car roof box1.auto roof box
2.car roof top box
3.roof box for car
ABS vacuum thermoforming car roof box
car roof box,vacuum forming plastic,OEM design
car roof box
car top box
roof rack box
the max is 3000*2000*800mm
high quality,strong,durable,eco-friendly,UV/UL-resistant,
outdoor ,dual opening
high quality,strong,durable,eco-friendly,UV/UL-resistant,
outdoor ,dual opening
OEM &ODM is acceptable
ABS box,steel base trestle
logo painting are available
professional engineer, expertly in CAD, UG, Pro-E and Solidworks for mould making.
products details:
item name |
ABS vacuum thermoforming car roof box |
color |
white |
material |
plastic,steel |
thickness |
5mm |
size |
133*85*37cm |
process type |
vacuum forming |
I. What's vacuum forming?
Vacuum forming is a process in which a thermoplastic sheet is heated to the appropriate temperature, stretched around or into a mold or pattern, and conformed to the mold by applying vacuum pressure between the mold surface and the plastic sheet. Because heating of the material to be formed is required, vacuum forming is considered a thermoforming process.
II. Vacuum Forming Machined process:
1. Extruding plastic sheet: |
ABS, HIPS, PP, PE, PC, PMMA resin granules are extruded or co-extruded into thermoplastic sheet or plate that textured, smooth, gloss or matt, fire retardant and UV resistant |
2. Vacuum forming: |
After being heated, the plastic sheet is stretched onto or into a mould, and held against the mold by applying vacuum between the mould surface and the sheet to form designed shapes. |
3. Cooling to keep shape: |
Once formed the plastic need to cool before being released from the mould. To speed up the cooling cycle, fans are fitted and activated once the plastic part is formed. |
4.Machine large products: |
Our machine could be restructured to make larger plastic vacuum forming plastic products, with maximum dimensions of 3000*2000*800*10mm (L*W*H*T) |
5. Trimming edges: |
Extra material is firstly trimmed before more accurate processing. Sawing is often used in the stages. Polishing is made additionally to smooth the edges. |
6. Drilling holes: |
Drilling often follow the trimming. Other post forming processes include decoration, printing, strengthening, reinforcing and assembly. |
7. CNC Processing: |
For more accurate and faster speed vacuum forming plastic products processing, CNC is often used. The machine is computer programmed to select correct cutting tools and angle to suit each area. |
8. Examination and checking: |
Before packaging, all our vacuum forming plastic products will be carefully checked in terms of dimensions, surface finish, strength, color requirements and so on. |
9. Cleaning and Packaging |
All vacuum forming plastic products are cleaned before packaging. Products are wrapped with plastic film to prevent scratches and cartoon boxes are used or other methods are applied as required. |
About us:
Amei Brothers is a professional vacuum forming products manufacturer in Shenzhen.The max size we can do is 3000*2000*800mm.The thickness can reach 10mm.The materials include PMMA,ABS,PP,PE,PET,PETG,etc.
We can produce good according to your design.If you have any pictures or designs, pls send it to us.It would be appreciated if you could provide us 3D drawings.
- We are able to do silkscreen, plating, spraying.
- We can add your own logo. we are largest manufacturer of vacuum forming products as customer design in Shenzhen,
- We have our own experienced mould technicians and CNC mould machines.
- We have adopted vacuum thermoforming method in order to minimize the product development cost for customers; we provide one stop service including mould design.
Welcome to order!
