Specifications
hot roll stamping machineMicro-computer control and pneumatic component drive;Stamping pressure, temperature and
hot roll stamping machine
Specification:
1. Micro-computer control and pneumatic component drive;
2. Stamping pressure, temperature and time are adjustable;
3. Worktable could be adjustable for forth/back move, operate safely and rapidly;
4. Worktable could be adjustable forward and backward, left and right, as well as turned reelingly;
5. Feeding paper and collecting paper automatically,as well as adjust speed;
6. According to different height of workpiece, cylinder stroke and the height of printing head
could be adjusted by cylinder tune-way nut and handle respectively;
7. Available for workpiece with round surface, dismantle shuttle table for flat printing.
Technical Parameters:
Heating Plate Size:100*168mm
Work Table Size:108*108mm
Stamping Stroke:25mm
Range of Hot Stamping Temperature: From Room Temperature to 280 centigrade
Max.Height of Workpiece:95mm
Range of Hot Stamping Pressure:<130kgf
Max.Speed of Hot Stamping:1000pcs/hr
Power:220V 50HZ
Electric Thermal Power:900W
Pressure of Air Supply Source:4-7bar
Air Consumption:<58L/min
Overall Size:630*580*1385mm
