Specifications
electric carbon fiber heating element1.Customized sizes and shapes are accepted
2.Insulation material: PET
3.Battery powe
Heating element
Specification:
Description | Parameter |
Certification | CE/ROHS |
Voltage range | 1.5v to 36v |
Power density range | 0.07w/cm2~2.5w/cm2(0.19w/inch2~16.13w/inch2) |
Using temperature range | -60~200°C(-140~392°F) |
Width range | 10mm~500mm(0.39"~19.68") |
Length range | 10mm~1800mm(0.39"~70.86") |
Thickness range | Standard:0.126~0.266mm(0.005"~0.01") |
Plug | Chinese,British, American, European and so on |
Quality guarantee | 1 year |
Life | more than 4 years(normal useful) |
MOQ | 500 piece |
OEM and ODM is welcome,can print your logo | |
Basic information
1. Insulation: UDC500V>=200M ohm
2. Dielectric strength: UAC>=2000V
3. Operation temperature: <=232C
4. Wattage density: <=1.1W/cm2 or <=6.5W/cm2(with thermostat)
5. Thickness: <=0.2mm Can bent at any angle
6. Weight: <=278g/m2
Function
Semi-transparent, flexible and extremely thin with excellent dielectric strength, Polyimide film is ideally suited for the manufacture of etched foil heaters.
Heaters can also be exposed to vacuum with low out gassing and to radiation.Long time keep warm.
Primary Competitive Advantages
Flexible heater, which is laminated between insulating layers such as Kapton, polyester, is a kind of thin, flexible etched foil heating element
1. Instruments temperature control: Gyro-accelerating detector, tail-wing operating device, aero-photographic apparatus
2. Medical instruments: Disinfection, keeping blood, injections and drips
3. Test and research: Crystal ovens, mechanically-heated structures, IC testers and flasks
4. Agriculture and animal husbandry: Seedling breeder, raising chicken and pigs, breeding fish, incubators, electric blankets for stock and poultry
5. Transportation: Car mirror and signal defogging, water tank heating
