Specifications
plastic crusher1.Lower Noise
2.Wearproof Blades
3.Higher Output
4.Tailor-made crushing mesh screen
high quality SWP400 plastic pet shredder
Structure Characteristic:
1. The cutter is made of excellent tool steel and under special heat treatment, so it features in high hardness of cutting edge.
2. The cutter is designed as adjustable installation mode, when the cutting edge is blunt, it can be grinded and installed repeatedly.
3. Rotary cutter rack of rotor is ranged in ladder mode, so it can separate dynamic load. Improve single cutter’s cutting torque and reduce power consumption.
4. Insulative structure design can reduce operational noise and improve working environment and precision.
5. It is equipped with phase-sequence over load protective, which can accurately connect with outer power supply, and also can shut off the power timely during the state of phase loss for electric motor and over load.
Main technacial parameter:
Model |
SWP200 |
SWP210 |
SWP320 |
SWP400 |
SWP630 |
Rotary knife diameter(mm) |
200 |
210 |
320 |
400 |
630 |
Number of turning knife |
3 |
3 |
6/2 groups |
5 |
9/3 |
Turing speed of knife(r/min) |
870 |
500 |
650 |
500 |
480 |
Number of fixed knife |
2 |
2 |
2 |
2 |
4/2 |
aperture of screen panel |
φ8 |
φ8 |
φ8 |
φ10 |
φ10 |
Crushing capacity(kg/h) |
50-110 |
80-120 |
250-350 |
350-450 |
700-850 |
power (kw) |
4 |
4 |
11 |
13.2 |
44 |
Size of feeding gate(mm) |
240×350 |
250×230 |
500×280 |
375*320 |
820*610 |
weight(kg) |
300 |
320 |
1400 |
980 |
5000 |
Outline dimension(mm) |
1000*590 |
800*600 |
1613*1150 |
2500*1200 |
2500*1550 |
Machine image shows:
