SGFM-1100 AUTOMATIC THERMAL FILMLAMINATING MACHINE
- 20 Set / Sets per Month
- NINGBO
- T/T
- Single-ended carbon fiber heat lamps 500mm 800w infrared heat lamps
- 1300w 670mm far infrared heat lamp frosted carbon fiber heat lamps
- 220v 1300w 670mm infrared carbon fiber heating lamp frosted carbon fiber heat lamps
- 400mm 600w infrared quartz lamp replacement carbon fibre heating lamp
- 400mm 600w infrared quartz heating element carbon fiber quartz tubes
- 230v 1200w infrared paint lamp infrared carbon fiber heating lamp for DTF machines
Product Details
Condition: | New | Application: | Other, Machinery & Hardware | Packaging Type: | Cartons |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Pneumatic |
Voltage: | no | Power: | 40KW | Place of Origin: | Zhejiang, China |
Brand Name: | YIZHAN | Model Number: | SGFM | Dimension(L*W*H): | 3500*2020*2020mm |
Weight: | 2500kg | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Product Description
SGFM series automatic thermal film laminating machine is a compound eauipment based on thermal film and paper.This machinecan realize the paper feeding,laminating,separating and temperature control full automatically.The electric system is controlled by PLC and with toch screen operation.The heating roller is heated up through the circulation of heated oil in order to insure the accuracy of Iaminating temperature.This machine is with high degree of automatization,easy to operate,highspeed ,big pressure and high it will be the first choice for large ang medium enterprise bacause of its high performanceprice ratio.
Construction features
1.Pre-stack paper feeding system:Collect paper before working.
2.Man-machine interface system:5.7inch colour touch-screen.it can be easy to operate,intuitive,and input directly the paper
size over lapping distance and laminating speed,and can check the machine working condition at any time.
3.Paper separating system:It can separate the paper into sheet automatically after lamninating.
4.Automatic paper stacking system :It can collect the laminated paper after separating.It is also equipped with pneumatic
shoot paper device.
5.Automatic paper rewinding system:It can rewind the laminated paper if it not needs paper separating.
6.We adopt the advanced air shaft to place the film and rewinding shaft.and its tension can be adjustable.
Main technical variables
Model | 1100 |
Max. Paper | 850×1020mm |
Min. Paper | 350×400mm |
Paper. Thickness | 125-500g/m2 |
Max. Laminating Speed | 0-60m/min |
Total Power | 40kw |
Total weight | 2500kg |
Overall Dimensions | 3500×2020×2020mm |
1. Warranty
1 year limited warranty after installation.If the spare parts is broken in the warranty
period , we will send a free replacement parts to you .
2. Installation and Training
We can send 1-2 engineers to buyers factory to install and set up the machines and
training, but all the charges for the engineers should be paid by buyer.
3. Quotation
The quotation is available in 60 days
