Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > QNB-600 Fully Automatic Lever Arch File Making Machine
QNB-600 Fully Automatic Lever Arch File Making Machine
US$ 40,000 - 70,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Book
Packaging Type:
Film
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lever Arch File Making MachineryUS$ 40,000 - 70,000MOQ: 1 Set -
TY-QFM Series Paper Box Making MachineUS$ 40,000 - 70,000MOQ: 1 Set
-
TY-QFM Series Automatic Carton Box Making MachineUS$ 40,000 - 70,000MOQ: 1 Set
-
TY-QFM Series Fully Auto Gift Box MakerUS$ 40,000 - 70,000MOQ: 1 Set
-
TY-QFM Series Fully Automatic Gift Box MakerUS$ 40,000 - 70,000MOQ: 1 Set
Condition
New
Application
Other, Book
Packaging Type
Film
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380v
Power
11kw
Place of Origin
Zhejiang, China
Brand Name
YIZHAN
Model Number
QNB-600
Weight
2700kg
Dimension(L*W*H)
L8500*W2250*H1440mm
Certification
CE Approval
After-sales Service Provided
Engineers available to service machinery overseas
Lever arch file making machine(Book cover making machine)
Features
1.The feeder in this machine adopts backpush feeding system , which is controlled pneumatically,
and its structure is simple and reasonable.
2.The width between stacker and feeding table is adjusted concentrically in the centre.
2.The width between stacker and feeding table is adjusted concentrically in the centre.
The operation is very easy without tolerance.
3.New designed copper scraper cooperates with the rubber more compactly, effectively avoiding paper winding . And the cooper scraper is more durable.
3.New designed copper scraper cooperates with the rubber more compactly, effectively avoiding paper winding . And the cooper scraper is more durable.
4.Adopt imported ultrasonic paper tester for two pieces of layered paper, featuring in simple operation ,
to keep two pieces of layered paper from entering into the machine at the same time effectively.
5.The cardboard feeding table is controlled by linear guide line and stepping motor , its location is correct and quick.
6.In the cardboard feeding table, the machine can automatically stop when lack of paper to reduce the paper waste.
7. Transport belt is equipped with a powerfull sucker motor for more the paper without any movement.
8. Paper feeding and positioning system adopt imported highprecise photoelectric control device to make the paper and cardboard location more accurate.
5.The cardboard feeding table is controlled by linear guide line and stepping motor , its location is correct and quick.
6.In the cardboard feeding table, the machine can automatically stop when lack of paper to reduce the paper waste.
7. Transport belt is equipped with a powerfull sucker motor for more the paper without any movement.
8. Paper feeding and positioning system adopt imported highprecise photoelectric control device to make the paper and cardboard location more accurate.
9.The automatic fouredge folding machine adopts special automatic anglerepair,edgerepair to ensure the qualification of finished products.
10. The whole machine adopts PLC control, featuring in simple operation.
The troubles are displayed directly on the computer touch screen , which helps the operator easily remove them.
Main technical parameter
Model |
QNB-600 |
Length of paper |
230-1030MM |
Width of paper |
160-600MM |
Thickness of paper |
100-200g |
Thickness of cardboard |
1-3mm |
Speed |
0-25sheets/min. |
Dimension |
L8500XW2250XH1440mm |
Power supply |
11kw |
Power consumption |
7.5kw/380v |
Weight |
2700kg |
