Specifications
bottle juice complete production linecapacity1000-20000BPH
materila ss304 food grade
10years experience
CE
bottle juice complete production line
Specification
1. For PET bottled juice producing plant
2. capacity 2000bph-24000bph
3. Auotomatic 3 in 1 filling machine
4. PLC programmable controller
5. Mitsubish frequency converter, Schneider electric components, Ariac cylinder products
Description
1.3-in-1 machine shortens the process of washing,filling and capping,so that it reduces the external pollution of product and makes the machine sanitary easier.
2.This machine is acceptable to use multi-type mon-carbonated liquid as filling material and various bottles as containers just by some spare parts changing and adjusting.
3.The machine reduces the labor and cost with high effciency during the producting and useds different kinds of bottles and caps.
Model | RCGF14-12-5 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-8 | RCGF40-40-10 | RCGF60-50-15 |
Capacity BPH/500ml | 3000 | 8000 | 10000 | 12000 | 18000 | 24000 |
Filling Pressure (MPa) |
0.4 | |||||
Applicable Bottle Type | Bottle Diameter: 50-100 mm Bottle Height : 150-320 mm Volume: 330-1500 ml | |||||
Applicable Cap Shape |
Plastic Screw Cap | |||||
Gas Source Pressure (MPa) |
0.6 | |||||
Gas Consumption (m3/min) |
0.2 |
0.3 |
0.4 |
0.5 |
0.55 |
0.6 |
Total Power (KW) | 4.6 | 5.03 | 6.4 | 8.07 | 9.56 | 11.18 |
Total Weight (kg) | 2500 | 4200 | 5800 | 7000 | 9000 | 12000 |
Outer Dimension (mm) | 2350* 1700* 2150 | 2830* 2030* 2030 | 3220* 2400* 2600 | 3450* 2510* 2710 | 3800* 2800* 2710 | 4510* 3400* 2900 |
Complete bottle juice Production Line
1)The machine is mainly used in the beverage filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic. The machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics.
2)The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.
