Working Pressure 150 psi-420psi TPU layflat water /oil hose,4",6", , with fittings,

Name: Working Pressure 150 psi-420psi TPU layflat water /oil hose,4",6", , with fittings,
Brand: Sunmoon
Price: USD $15 - 70 / Meter

FOB Price

USD $15 - $70 / Meter

200 Meters(Min.Order)

Supply Ability 20000 Meter / Meters per Month
Port Qing dao Shang hai Ning bo

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

Sunmoon

Model Number:

4",6",8",10"150psi~420psi ,equiped with fittings

Product Description

High pressure TPU hose is the company’s core product ,and it is a kind of lay-flat water and oil discharge hose(antistastic and inflamble ) .it consists of TPU liner ,polyester reinforcement and TPU cover.Their Nominal diameter, from DN25 to DN350,Working pressure ranges from 150PSI to 450PSI，and length ranges from 20m to 200m.It has the features of bearing high pressure,durable,Corrosion resistance, aging resistance,and transfers for water,oil , gas and other mediums.This hose produced by green and environmental materials ,and not polluting the transfer mediums,used for shale gas exploitation,coal mines,fuel and oil industries,water discharge,agriculture irrigations ,flood and fire disasters ,etc.

Products features

(1) Inner nominal diameter : DN25~DN350
(2)working pressure:90PSI~450PSI
(3)wall thickness:1.8mm~5.5mm

(4)bearing high pressure,durable,Corrosion resistance, aging resistance,and transfers for water,oil , gas and other mediums.
(5)working temperature:-40℃~+80℃(233K~353K)

Specification (inch)	Inner diameter	Working pressure		bursting pressure		Maxium wall thickness		Weight
Specification (inch)	mm	psi	bar	psi	bar	inch	mm	Ibs/ft	Kg/m
1“	26	145	10	435	30	0.1	2.5	0.2	0.3
2”	52	232	16	696	48	0.16	4.0	0.46	0.7
2.5“	64	232	16	696	48	0.16	4.0	0.52	0.8
3”	78	145	10	435	30	0.14	3.5	0.53	0.85
4“	102	145	10	435	30	0.16	4.0	0.62	1.0
4"	102	232	16	696	48	0.15	3.8	1.0	1.5
6"	152	406	28	1218	84	0.18	4.5	2.1	3.2
8"	203	290	20	880	60	0.16	4.0	2.47	3.7
10"	252	232	16	696	48	0.18	4.4	2.53	3.8
12"	305	203	14	609	42	0.22	5.5	3.46	5.2

Detailed Images

Company profile

Packing & Delivery

Package and Transportation

1.package

(1)square metal or plastic pallets,and stacking hoses,covered by protection covers.

(2)Rectangle metal reel and reeled the hose on it,covered by the protection covers.

2.Transportation : truck to ports,and shipping to destination.

3.Port: Qing dao,Shang hai .
