juice bottling machine/plants/machinery
1.high efficient hot filling machine/filler range from 3000bph to 30000bph, can apply to juice, tea, sport drinks, function drinks, etc.
2.Rinser/Filler/Capper Monobloc
Size of bottle: 500ml (300ml-1500ml) not returnable square or round PET bottle.
Closure type: 28~38mm standard plastic screw caps
Method of bottle transferring: By neck
Products: Tea/juice/sports drink/milk beverage.
Parameters:
Technical Data | ||||
Model | CGFR16126 | CGFR18186 | CGFR24248 | CGFR323210 |
The number of Washing, Filling, Capping | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 |
Producing capacity; The number of bottle(600ml)/hour | 3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 |
Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | |||
Pressure (kg/cm2) | 2~3 | |||
Motor power (kw) | Main motor 1.5kw | Main motor 2.2kw | Main motor 3kw | Main motor 4kw |
Outside vacuum pump power (kw) | 0.75 | 1.1 | 1.5 | 2.2 |
Overall dimension (mm) (LxWxH) | 2100x1400x2500 | 2460x1720x2650 | 3100x2100x2650 | 3500x2500x2650 |
Weight(kg) | 2500 | 3500 | 4200 | 5500 |
Specification
juice bottling machine washing filling &capper parts
juice bottling machine:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change of the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
7. Equipped with a constant temperature system, temperature controlled and circumfluenting automatically
