Home > Electrical & Electronics > Inverter > Power Inverter > On Grid Inverter 220 Volt 50 Hz 60Hz1000Watt Output for Grid Connected PV System

On Grid Inverter 220 Volt 50 Hz 60Hz1000Watt Output for Grid Connected PV System

Name: On Grid Inverter 220 Volt 50 Hz 60Hz1000Watt Output for Grid Connected PV System
Brand: Thinkpower
SKU: 106840995

Negotiable MOQ: 2 Units (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Thinkpower

Model Number:

T1500TL

Wuxi Thinkpower New Energy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Thinkpower

Model Number T1500TL

Output Power 1 - 200KW

Output Type Single

Size 375*480*136mm

Weight 17kg

Input Voltage 450V

Output Voltage 220V 230V

Type DC/AC Inverters

Output Frequency 50Hz 60Hz auto-selection

Output Current 8A

Specifications

On Grid inverter, 220 Volt 50 Hz, 1000Watt Output, for grid connected PV system, outdoor and indoor both OK.

On Grid inverter 220 Volt 50 Hz 1000Watt Output for grid connected PV system

Model No	T1500TL
DC side/Input parameters
Max. DC power [W]	1800
Max. DC voltage [Vdc]	450
Min. System start/Shut down voltage [Vdc]	150/100
MPPT voltage range[Vdc]	100~450
Max. input current [A]	10
Number of MPP trackers	1
AC side/output parameters
Nominal output power [W]	1500
Maximum output power [W]	1650
Nominal output voltage/range [V]	208,220,230,240/180~265
AC grid frequency/range [Hz]	50,60/±4.5 auto-selection
Maximum output current [A]	8
AC connection(with PE)	Single phase
Current distortion(THDi) [%]	1.5
Power factor [%]	99.9
Efficiency
Maximum conversion efficiency[%]	97.3
European efficiency[%]	97
MPPT efficiency[%]	99.9
Protection
DC reverse-polarity protection	yes
Short circuit protection	yes
Ground fault/residential current monitoring	yes
Grid monitoring	yes
DC/AC side varistors(thermally protected)	yes
General Parameters
Dimension(L/W/H)[mm]	375480136
Weight(kg)	14.5
Embedded DC Switch	Optional
Night Mode support	Optional
Night power consumption[W]	0.2
Isolation type	Transformerless
Protection degree	IP65
Operation temperature[ºC]
Heat Dissipation	Convection
Acoustic noise level[dB]	25
Altitude[m]	2000 without power derating
Storage temperature[ºC]	-30 ~ 80
Real Time Clock module	yes
LCD Display	Graphic and digital segment
Communication Interface	Standard WiFi
Certificates	CE,VDE4105,VDE0126,G83,G59,SAA,CQC
Warranty: 5/10/15years yes/optional/optional/optional * More technical characteristics are avaliable on demand and customized.
