E Waste Recycling Refrigerator Recycling Machine/ High Recycling Rate

Dear Customer:

1. Have you passed the EIA (Environmental Impact Assessment) for recycling this resource?

2. Project Time Table.

3. Any regulations for recycling in your cuntry.

4. Wearhouse layout.

5. Local power supply.

6. Capacity demands.

7. Maximum size of the materials.

8. Any pictures helpful.

Basic information:

1, Equipment capacity : 15-20 pcs/hour

 2, Dimensions: 35000*10000*7200mm

 3, Equipment power: 176 Kw

 4, Power supply: three-phase AC 380V/50Hz,

 5, Nonferrous Recovery rate  by weight>:≥90%

 6,Ferrous Recovery rate by weight>: ≥ 95%

 7, Plastic Recovery rate: ≥90%

 8,PUR recovery rate by volume> : 90%

 9,Noise, dust leaks and exhaust gas emissions in line with national standards and requirements

 10, Equipment appearance and color: according to corporate standards.

2. Product Introduction

2.1 Work Flow

1.The first is to manually disassemble refrigerator cabinet and resulting plastic, wire, glass, circuit board. The

2.second is to reclaim refrigerant to ensure it would not pollute atmosphere.

3.The third is to dismantle compressor and condnser.

4.The fourth is to multi-level shred refrigerator body in shredder. In the shredder polyurethane is sucked out by air pump.

5.The fifth is to separate iron by permanent magnet.

6.In the last step aluminum and copper are separated by eddy current.

The entire processing Equipment is located in an enclosed workshop. Exhaust gas and dust can be discharged by high pressure positive blower after being processed by activated carbon adsorption and hop-pocket dust extraction.

Major components

3. Input and Output

Input

Output

4. Product Overviews
