Specifications
200W LED Moving Head stage lighting equipmentlight source: 90W White LED
DMX512 control signal
CE & RoHS
M-LS090 LED Moving head light (SPOT) adopts LED light source, can create a very sharp beam and clear images, as well as a variety of shapes.
Specification and Parameter
| Technical DataModel | M-LS090 |
| Power Supply | AC100V~240V, 50/60Hz |
| Power Consumption | 200W max |
| Light Source | 90W White LED |
| Illumination intensity | 20,000LX@Lm |
| Color wheel | 7 colors plus white by Hall positioning, with rainbow effect, color wheel forward and reverse rotation available |
| Gobo Wheel | 7 rotating Gobos plus white by Hall repositioning, with shaking function, speed adjustable, Gobo wheel & Gobo forward and reverse rotation available, speed adjustable |
| Prism | 3-facet, bi-direction and speed adjustable |
| Focusing | independent linear adjustment |
| Dimmer | 0~100%, linear adjustment |
| Strobe | variable strobing 1~15 flash per sec, build-in strobe macro-function |
| Reset function | independent repositioning channel, can be reset for every chip individually) |
| X/Y Movement Range | Pan 540°, Tilt 280°by Hall repositioning, with Pan/Tilt position correction, X/Y movement speed adjustable |
| 16 bit Pan/Tilt movement resolution | |
| Control Channels | 20CH |
| Control Signal | DMX512 |
| LCD Display | displaying brightness adjustable (10-100%), back-light function and can be activated when press any buttom |
| Dimension | 505mm×490mm×690mm |
| Net Weight | 13.6kg |
| Material | flame retardant plastics |
| Light source useful life | Ave 100,000 hrs |
Item Pictures:
M-LS090-led-moving-head-light--Hunan TV Entertainment channel stage
CE & RoHS certified:
Moving Head Light Workshop
About MHG
Established in 2001, we are a professional manufacturer of stage lights and LED display, we have 6 product lines including LED Lights, Moving heads, cool lights, effect lights, color scrollors and special LED display plant, products are normally CE & Rohs certified.
And we are the member of China Entertainment Technology Association, of Seminar of China Television Broadcasting Institution, and of Society of China Illumination. Our ISO 9001 / 2008-certified factory has more than 200 workers and over 30 R&D staffs.
