Digital Audio to Analog Audio Converter

Specifications

Features:

1. 4-Ports SPDIF (2×Toslink and 2×Coaxial) digital audio input, switch to 1-Port SPDIF/Toslink output and one L/R analog audio output and one headphone output.
2. Uses 192KHZ/24bit DAC.
3. Support digital audio formats: Dolby AC3, DTS, THX, HDCD, LPCM for SPDIF output.
4. Support LPCM digital audio converted to analog audio output.
5. Automatic identification input digital audio signal format, when non-LPCM input, analog output mute.
6. Input status indication. When no audio or error data input, the input port indicator starts to flash.
7. A key switch, easy operation.
8. Headphone amplifier output, can drive the general 3.5mm earphone.
9. High tone quality, low noise.
10.Power-off memory .
11.DC5V/1A power adapter.

Specifications:

Analog Audio Output Support audio format ………………….…….…….….….……………… PCM/LPCM
DAC sample frequency range…………………………………………………………………. 32~192 KHz
DAC Bit rate range…………………………………………………………………………………..16~24 Bit
Digital input level………………………………………………………………………………..0.1~1Volts p-p
L/R output level(1kHz@0dB).....................................................................................................1V RMS
Headphone output power (1kHz@0dB RL=32)……………………………………………………….30mW
SNR @ 0dB(CCIR/ARM)………………………………………………………………………………….90dB
Distortion……………………………………………………………………………………………………0.1%
Frequency response……………………………………………………………………………..20Hz~20KHz
Max working current …………………………………………………………….……….…….….……100mA
Power adapter format Input ……......….….…….…….…….….. AC 100V~240V 50HZ/60Hz, DC5V/1A
Operating Temperature range ……..…………….………………………………………………-10 to +55°C
Storage Temperature range………………………………………………………………………-20 to +60°C
Operating Humidity range ………………………….….……….………...10 to 90%RH (No Condensation)
Storage Humidity range………………………….….……….……………..5 to 95%RH (No Condensation)
Case Dimension (L x W x H) ………………………………….……………………………..85x62x21 (mm)
Weight …….…………………………….………………………………………….……………………….130g

Package contents:

1,  Main unit                                      1pcs
2,  AC power adapter                      1pcs
3,  User manual                               1pcs
