Specifications
This converter enables you to connect the DVD, PSP, XBOX 360, Wii NTL, TV to the HDMI DisplayerYPbPr/RGB + R-Audio-L to HDMI
The HDCYUV0101 Converter use single YPbPr+SPDIF source,accessing to single HDMI1.1 sink. The Converter allows one YPbPr+SPDIF device to be converted easily to one HDMI1.1 monitor or projector.
FEATURES
l One YUV/YPbPr/YCbCRr+ SPDIF (Optical+ Coax) input signal convert to one HDMI 1.1
sink devices
l Support video input : Up to capture YPbPr1080p, 330Mbandwidth,50/60H
l Support audio SPDIF input : DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
l HDMI output : Support up to 1080p/60HZ, same format as input
l HDCP 1.1 protocol compliant
l Support CEC
l Support audio format output : DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
l LED indication : when source or sink is working, LED relative to is light.
l Support output up to 20metres AWG26 cable length
l No loss of quality
l Installs in minutes
l Need DC5V/1A power supply
CONNECTING AND OPERATING
1. Connect YPbPr+ SPDIF from YPbPr source devices into Converter input.
2. Connect one cable from HDMI1.2 display (monitor or projector) into the Converter
outputs.
3. Connect 5V power supply to the HDCYUV0101 Converter.
