Hdmi Digital Audio Splitter

Hdmi Digital Audio Splitter thumbnail-1
Hdmi Digital Audio Splitter photo-1
Negotiable MOQ: 50 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ASK
Model Number:
hdsp0104m
Contact Supplier Request Quote Chat Now
Shenzhen ASK Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ASK
Model Number hdsp0104m

Specifications

1X4 HDMI splitters, full 1080P ,3D ,1.3V
1.one HD signal split to four HD signal display,hdmi 1.3 certified
2.1 input 4 output

1X4 HDMI splitters, full 1080P ,3D ,1.3V



1X4 HDMI splitters  with amplifier
1.one HD signal split to four HD signal display,hdmi 1.3 certified
2.1 input 4 output
3.3D supported

4.hdmi 1.3V





The 1x4 HDMI Splitter use a single HDMI source,accessing to multiple HDMI sinks. The Splitter allows one HDMI devices to be split easily to four HDMI compatible monitors or projectors. The Splitter can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.





FEATURES



 One HDMI 1.3 input signal split to four HDMI 1.3 sink devices

HDCP 1.2 protocol compliant

Support CEC

Support deep color 30bit, 36bit

 Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC

Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

Support signal retiming

Support input up to 15metres AWG26 HDMI 1.3 standard cable length,

output up to 25metres AWG26 cable length

 No loss of quality

Installs in minutes

Need DC5V/1.4A power supply



CONNECTING AND OPERATING



1.              Connect one cable from HDMI source devices into HDMI Splitter input.

2.              Connect one cable from each display (monitor or projector) into the HDMI Splitter outputs.

3.              Connect 5V power supply to the HDMI 1x4 Splitter.



SPECIFICATIONS:                               HDSP0104M





HDMI version. HDMI 1.3

HDCP version....HDCP1.2

HDMI resolution ....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

Support video color format ...24bit/deep color 30bit,36bit

Support audio format.DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

Max ....10.2Gbps

Input/Output TMDS signal ... 0.5~1.5Volts p-p

Input/Output DDC signal .. 5Volts p-p (TTL)

Input cable distance..... ...≤15m HDMI AWG26

Output cable distance....≤25m AWG26 HDMI 1.3 standard cable

Max working current.....600mA

Power adapter format..Input: .....AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1.4A

Operating Temperature range... (-15 to +55)

Operating Humidity range...5 to 90%RH (No Condensation)

Dimension (L x W x H)     .115x60x24 (mm)

Weight.....475g
