HDMI Wireless Extender Hdmi Extender

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

ASK

Model Number:

HDE004

Place of Origin:

Guangdong, China

Shenzhen ASK Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen/HK

Delivery Detail:

Delivery time depends on order quantity.

Brand Name ASK

Model Number HDE004

Place of Origin Guangdong, China

Specifications

Supporting the video HDMI interface at the maximum of 1080P60Hz Supporting HDMI1.3 and HDCP1.2 protocols
Supporting the EDID

Product Features

*Instant wireless HD AV transmission;

*Transmission range in the vacancy indoor environment 30m;

*Supporting the video HDMI interface at the maximum of 1080P60 Hz;

*Supporting HDMI1.3 and HDCP1.2 protocols;

*Supporting the EDID function;

*Supporting the CEC function (for the receiving and display devices);

*Supporting the IR extension transmission function;

*Transmission power 12 dBm;

*Supporting the point-to-point transmission function currently

*which can be expanded to the point to multi-point or multi-pointto multi-point transmission function;

*Supporting the AES128-bit image encryption Function;

*Supporting the reverse back-transmission channel at the maximum rate of 100 kbs;

*Supporting OSD display;

*Supporting WHDI 1.0 specification.

Technical Specifications

Video formats supported	TV 1080p, 1080i, 720p, 576p,480p PC: VGA(640X480), SVGA(800X600), XGA(1024X768), SXGA(1280X1024)
Audio formats supported	PCM,DTS, DOCBY DIGITAL
RF communication system	MIMO
Modulation mode	OFDM
Maximum transmission power	12dBm
Image transmission distance	≥30m
Image delay	<1 ms
Transmission/receiving antenna mode	Built-in
Operating frequency	5.1~5.9GHz
IR carrier modulation frequency supported	38KHz
Operating power supply	100-240V AC mains, 5V 2A DC power
Storage temperature	-20~80OC
Storage temperature	-10~50 C
