Help CenterHDMI Matrix Swithcher 8x8
Related Products
Specifications
8*8 matrix speciality:1.HDMI V1.3,RS232, IR control
2.8 in 8 out
3.Input 15M,output 25M
4.1080P/60HZ 10.2Gbps True Matrix
The 8x8 HDMI matrix access to eight HDMI sinks, using eight HDMI sources. The matrix
allows eight HDMI devices to be switched or split easily to eight HDMI compatible monitors or
projectors.
Hdmi matrix (8 hdmi signal input 8 hdmi output)
1. HDMI V1.3B ,HDCP 1.2.
2. 1080p/60HZ 10.2Gbps.
3. Support deep color 30bit,36bit
4...3D support
FEATURES
l Eight HDMI 1.3 input signals switched or split to eight HDMI 1.3 sink devices.
l HDMI Rev 1.3b compliant.
l HDCP 1.2 protocol compliant.
l Support CEC.
l Support deep color 30bit, 36bit.
l Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC.
l Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD.
l Support signal retiming.
l Support input up to 10 metres AWG26 HDMI 1.3 standard cable length, output up to 20
metres AWG26 cable length.
l Inputs can be switched with the IR remote control,also can be controlled by eight buttons.
SPECIFICATIONS: HDMX0808
HDMI version……………………………………………………………………………HDMI 1.3b
HDCP version…………………………………………………………………………....HDCP1.2
HDMI resolution ………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format …………………………..…………….24bit/deep color 30bit,36bit
Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Max transmission bandwidth…….………………….…………………………………..6.75Gbps
Input/Output TMDS signal ………….…………………………..……………… 0.5~1.5Volts p-p
Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL)
Input cable distance..…... ……………………….……………….………….≤15m HDMI AWG26
Output cable distance…………………………….…...≤20m AWG26 HDMI 1.3 standard cable
Max working current…………………………………………………………………………...2.0A
Power adapter format………………Input:AC (50HZ, 60HZ) 100V-240V; Output: DC24V/3A
Operating temperature range……..…………….………………………………… (-15 to +55°C)
Operating humidity range………………………….….……….5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….………………………540X180X100 (mm)
Weight…..………………………………………………………..…….………………………4000g
8x8 true matrix RS-232 INTERFACE
