Specifications
HD Multimedia Integrator1: 1xS-video, 1x AV, 1x VGA, 3x HDMI audio and video signal inputs, converted to 1x HDMI output
High Quality HD Multimedia Integrator
FEATURES:
l 1xS-video, 1x AV, 1x VGA, 3x HDMI audio and video signal inputs, converted to 1x HDMI output
l Support HDMI output up to 1080P/60Hz, the HDMI signal input support 3D HD source film (24fps)
l Support 30bit, 36bit deep color
l Support audio separation output, includes a fiber output and L&R analog output
l Supports 3 modes of EDID management for audio formats, can switch among built-in EDID (2CH/5.1CH) and external EDID (TV).
l PAL/NTSC automatic video format
l No loss of quality. Support input up to 15metres AWG26 HDMI standard cable length, output up to
20metres AWG26 cable length
l Easily switch between devices manually or with the IR remote control
l Plug and play
l Support 2x USB 1A current charging interface, and support charging for Apple device
l Built-in 4 ports 10/100M network switch, so easy to connect to the internet
l DC5V/2A power supply
PACKAGE CONTENTS:
1. Main unit 1pcs
2. AC power adapter 1pcs
3. Remote controller 1pcs
4. User manual 1pcs
SPECIFICATIONS: HDCN0019M1
HDMI input Max resolution …………………………………………………..up to 1080P/60Hz/ 3D(24fs)
VGA input resolution..…………….……..…………….……..…………….……up to 1920 x 1080 @60Hz
HDMI output resolution ………………………………………………………up to 1080P/60Hz/ 3D(24fs)
HDMI video color format …………………………………………………………………..24bit/deep color 30bit/36bit
HDMI audio format……………………………………DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
HDMI Max bandwidth…………………………………………………………….…….….…………225MHz
HDMI Max baudrate……………….…….………….……………………………….…….……… 6.75Gbps
Input/Output TMDS signal ………….…………………………….…..…….………0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………………………………..…….…….…….……5Volts p-p (TTL)
HDMI Input cable distance…...……………………….……….……. ≤15m AWG26 HDMI standard cable
Output cable distance ….…….…….…….…….…….…….…….……≤18m AWG26 HDMI standard cable
Switch port number…………………………………………………………………………………….4X RJ45
MAC address……………………………………………………………………………………………………….2K
Network bandwidth……………………………………………………………………Auto-negotiation 10M/100M
Network protocol…………………………………………………………IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Max working current……………………………………………………………….……….…….….…….. 1A
Power adapter format Input: ……......….….…….…….…….… AC 100V~240V 50HZ/60HZ; DC5V/3A
Operating Temperature range……..…………….………………………………………………-10 to +45℃
Storage Temperature range………………………………………………………………………-20 to +60℃
Operating Humidity range………………………….….……….……….10 to 90%RH (No Condensation)
Storage Humidity range………………………….….……….……………5 to 95%RH (No Condensation)
Product size (L x W x H) ……………………………….…………………………………280x170x40 (mm)
Weight…….…………………………….………………………………………….………………960g
