Specifications
By the button switch, it can choose 720p or1080p outputAdaptive PAL / NTSC standard
FEATURES
lOne CVBS signal and R/L analog audio signal input
lOne HDMI Signal output(the output HDMI signal resolution up to 1080p/60Hz)
lBy the button switch, it can choose 720p or1080p output.
lAdaptive PAL / NTSC standard.
lSupport output up to 15 meters AWG26 cable length
lNo loss of quality
lInstalls in minutes
lNeed DC 5V/1A power supply
SPECIFICATIONS: HDCN0007M1
Video input…………………………………………….………………..…………………..CVBS
Analong audio Input ….………………………………………………………………R/L Analog
HDMI output ……..……….….………………………………….…720P/ 60Hz or 1080p/60Hz
CVBS Signal input……………………………. ………………….......0.5~1.0Volts p-p 75ohm
Analog audio (R/L) input …………………………………………...0.5~2 Volts p-p 47k ohm
Output DDC signal…………………………………………………………….. 5Volts p-p (TTL)
Max working current……………………………….…………………………………..….600mA
Output Cable Length…………………………………..…≤15m,use the 26AWG HDMI Cable
Power adapter format………………………………………………………………….DC5V/1A
Working Temperature Range……..…………….………………..…………..…….(0 to +40°C)
Working Moisture Range………………………….…………5 to 90%RH (No Condensation)
Dimension (L x W x H) …………………………………………………..68x51.6x16.5 (mm)
Weight…..…………………………………………………………..………………..………. 65g
