<h2>dvi splitter 1x2 with dual-link for tv</h2>
| Feature |
1X DVI-D input and 2/4/8/16X DVI-D output Support dual Link DVI-D signal transmission, resolution up to 3840X2160@30Hz Support resolution 640X480@60Hz to 3840X2160@30Hz, compatible with the HDMI 1080P standard Support for long distance signal transmission Installs in minutes, No loss of quality Supports wide range voltage DC input (DC5V~12V)
|
| Specification |
DVI interface type .. Dual link DVI-D Single link input/output resolution …………………………...............................up to 1920x1080@60Hz Dual link input/output resolution …............up to 3840x2160@30Hz Support video color format …………………………….24bit/deep color 30bit,36bit Max signal bandwidth……………………………..340MHz Max baud rate…………………3.4Gbps Serial Link Input/Output TMDS signal ……………………….0.5~1.5Volts p-p(TTL) Input/Output DDC signal …………………………. 5Volts p-p (TTL) DVI input cable distance…………………………………………≤10m AWM 20276 DVI standard cable DVI output cable distance………………………………………..≤10m AWM 20276 DVI standard cable Max working current ………………….0.8A/5V (DVISP002M1) Max working current …………….....1.2A/5V (DVISP004M1) Max working current …...1.5A/12V (DVISP008M1) Max working current …………...2.5A/12V (DVISP016M1) Power adapter …………………AC 100V~240V 50HZ/60Hz, DC5V/2A(DVISP002M1/DVISP004M1) Power adapter ……………….AC 100V~240V 50HZ/60Hz, DC12V/3A(DVISP008M1/DVISP016M1) Operating Temperature range ……..…………….…. -5 to +45℃ Storage Temperature range……………………………………………………………………. -15 to +55℃ Operating Humidity range ………………………….….……….……….10 to 90%RH (No Condensation) Storage Humidity range………………………….….……….……………5 to 95%RH (No Condensation) Case Dimension (L x W x H) ……………… 179x66x28mm (DVISP002M1) Case Dimension (L x W x H) ………………….277x136x27mm (DVISP004M1) Case Dimension (L x W x H) ……………….482x180x44mm (DVISP008M1) Case Dimension (L x W x H) ……………….482x180x66mm (DVISP016M1) Weight …….…………………………….………………………………………….…...370g (DVISP002M1) Weight …….………………………………………………….…...800g (DVISP004M1) Weight …….…………………………….……………………….…..1.5kg (DVISP008M1) Weight …….……………………………………...1.8kg (DVISP016M1) |
hdmi true matrix 4x4 with RS232, rj45 hdmi true matrix 4X2 with audio
Standard Package: Blister Box+ Instruction book + white box .Mostly,we could provide our Ai. diecut for customer to add their own design.Or We could also do customized package as customer's requirements.
dvi splitter 1x2 with dual-link for tv
Business Terms
| Accepted Delivery Terms: | FOB, CIF, EXW |
| Accepted Payment Currency: | USD, EUR, HKD, GBP, CNY |
| Accepted Payment Type: | T/T, L/C, Western Union, Cash |
| Nearest Port: | Shenzhen |
Company Profile
We arethe earliest developers and manufacturers committed to HDMI audio and video application system in China since 2004 with holding 20 patents.
By service our customers all over the world, we have consisted a super strong R&D team make up by 30 engineers which most with 6-10 years experience in HDMI and HDMI accessories products. Backed with vast experiences in design, engineering, manufacturing, we have build long term business with Samsung, Song, LG, Skyworth, TCL and Hair. We are not just manufactory for HDMI products, we are also provide HDMI application resolution for customer.
Factory Capacity
We strictly adhere to ISO 9001:2008 standards since we set up the factory by 2004. Also we are the holder for the certificate of ISO ,HDMI ATC, USB, UL, ROHS, CE, FCC and EMC. By implement the above high quality and technology standard, we are confident to make promise to every of our customer that all of our products is 3 years quality guarantee.
The published products are included HDMI splitters, switchers, converters, true matrixes, HDMI extenders and smart safe system products, but we are keeping publishi new product every month.
dvi splitter 1x2 with dual-link for tv
1. About sample: Sample can be ready with 5 days, for customized sample lead time is 20 days.
2. Payment service: T/T,30% deposit,70% before the dilivery.
3. After-sale service: We offered with 3 years quality guarantee.
4. Response service: We will reply you within about 24 hours.
5. Customize service: OEM and ODM.
A.How long about the samples ?
A1:About 3-5 days.
B.How long can be ready about the goods ?
B1:It usually takes about 30 working days,it is based on the detailed QTY.
C.Can you offer the OEM and ODM service ?
C1:Yes,of course,as we have our own design team.
D.What is the type of your company ?
D1:We are the earliest developers and manufacturers committed to HDMI audio and video application system in China since 2004 with holding 20 patents. We are also offered with product solution.
