Weighing Filling Machine FM-SW/20L
20L Barrel Weighing Machine (special for middle size barrel)
Weighing Filler FM-SW/20L Filler Head
FEATURES
1. Filling Method: Filling from top.
2. Control Mode: Manual setting filling way, micro switch control.
3. Conveying Mode: Roller Type Conveying without engine.
4. Own digital displaying filling quantity function, can finish multi-kinds filling quantity
setting.
5. Automatic peeled, based on net weight filling function.
6. Own vacuum withdrawing function to avoid anti-drip.
7. With manual & automatic micro switch control system function.
8. Dual speed control function to prevent splashing.
9. With emergent treatment to avoid misuse and protect power-off.
10. With SUS316 material of inside pipeline, which is liquid contact part.
Weighing Filler FM-SW/20L + Lids Capping Machine FC-P(4-20L Plastic Barrel)
Keep same 500mm roller height
APPLICATIONS
Weighing filling machine is made based on international technique, with filling and electronic weigh, electronic displaying functions. It is suitable for medium bucket filling of various kinds of viscous, non-viscous, corrosive and non-corrosive liquid.
SERIES
Type |
Name |
Weighing Range |
Filling Speed |
Air Supply |
Power Supply |
Dimension(mm) |
Weight |
FM-SW/20L |
Weighing Filling Machine |
5-20kg |
120-150pcs/hour |
165L/min |
AC220V 50HZ |
1020x650x1450 |
95 kg |
Weighing Filler FM-SW/20L + Capper FC-P (4-20L Plastic barrel)
Roller Height: on floor as required by customer
