Toys Metal Detector NC-PB

Portable Type Needle Detector NC-PB

.^_^.With light yellow string, easy to handle, simple to operate and detect on product

FEATURES

1. Streamlined design, soft light gray tone, light and easy utility.

2. Real-time signal induction.

3. Use one 9V battery, low power consumption, easy to change, and with good stability.

.^_^. LED "heart" lamp + With transparent platic box + Present 2pcs 9V batteries

PURPOSE

1.Detecting broken needles and magnetic metal impurities in sewing products, such as: small

garments, knitting products, sweaters, stockings, zippers, buttons, shoes, hats, toys, crafts, plaited products etc.

2. Used for small range detection to locate exact position of magnetic metals.

3. Work together with auto-conveying needle detector, used for detect and locate exact position of magnetic metals in warned products.

.^_^. see from right side + see from leftside

SPECIFICATIONS

1. Type NC-PB
2.Detection Method Magnetic induction
3.Detection sensitivity 0-60mm height by steel needle (¢0.7*L25mm)
4.Detection adjustment 0 step (no adjustment)
5.Alarm method Buzzer+ LED Lamp / Vibration

6. Power source 1pc 9V battery
7.Weight 200g

8. Dimension 160mm(L)*55mm(W)*45mm(H)

Above specification is under standard test condition. As different working condition, different environment, different products shape will effect above standard data.
