Easy Operate Full-Automatic Double Sides Labeling Machine LM-AD

Automatic Dual Sides Bottles Labeling Machine LM-AD

Touch Screen Operational Panel

FEATURES

1. Labeling smooth, no wrinkle, no bubbles, with high precision and stability.

2. With multi-functions, can achieve round bottles, cone bottles, square bottles position locating labeling.

3. Labeling speed, conveying speed and sub-bottle speed can be adjusted without steps, be convenient to adjust based on actual requirement.

4. Bottles standing labeling, can work separately, also can work together with production lines.

5. With strong mechanic structure, and working stably.

6. With automatic sub-bottles function, excessive bottles storage function, circumferential positioning labeling function, each function can be chose freely.

7. Mechanic parts with structured combination and ingenious design of tags winding, in order that different products change and tags winding get simple and time-saving.

8. Own the function of calibration when no tags and automatic inspection function.

9. Main machine material is made of stainless steel and high quality alloy material, overall structure is solid and beautiful.

10. Adopts standard PLC + sensor control system.

11. With compact structure, small occupation area, convenient to move and install.

12. With error alarming system and production counting function.

13. Optional function and spare parts
Hot code printer /coding jet function

automatic material feeding function

Other function: based on customer’s actual requirement.

APPLICATIONS

1. Applicable Tags stickers, electronic monitoring code, bar code etc.

2. Applicable Products Requiring products on flat surface, arc, circle surface, concave, convex or other surface stick labels.

3. Applicable Industries Widely used for foods, toys, daily chemical, electronic, pharmaceutical, hardware, plastic & rubber, printing industries.

4. Applicable Examples PET round bottles, plastic bottles labeling.

SPECIFICATIONS

1. Type LM-AD

2. Labeling Accuracy ±1mm (not including products, tags error)
3. Labeling Speed 20~280 pcs/min (based on products size)

4. Applicable products size

Flat / square bottles Width≥20mm Length≥20mm 20≤Height≤350mm
Round /cone bottles 20≤diameter≤ 150mm 10≤height≤350mm
5. Applicable tags size 15≤Width≤200mm Length 10-200 mm Inner diameter 76 mm
6. Rated Output 4.2KW
7. Machine Size 2700×1500×1500mm(L×W×H)
8. Power Supply 220V 50/60HZ
9. Machine Weigh 180Kg
