Plastic Bucket capping machine FC-P
- 50 Set / Sets per Month
- Shanghai Port China
- T/T
- Beer bottle filling equipment line beer bottle washer filler and capper bottling machine
- Manual Plastic Bottle Cap Sealing Machine Bottle Hand Sealing Machine
- Food Tin Can Foil Induction Sealing Machine From Foshan Supplier
- BF2000A Automatic Bottle Washing, Filling And Capping Line
- BF2000 Production Line Of Washing Filling And Capping Machine
- BIOBASE China Automatic Capping Machine BK-AC10 for Automatic Tightening and Loosening of Various Tube Automatic Capping Machine
Product Details
Condition: | New | Application: | Beverage, Chemical, Commodity, Food, Medical, Other, Beverage, Chemical, Commodity, Food, Medical, Food/Oil Barrel, Plastic Bucket, Coating Barrel, Paint Barrel etc | Driven Type: | Electric |
Automatic Grade: | Semi-Automatic | Voltage: | 220V | Power: | 110V/220V/380V, 50HZ/60HZ |
Packaging Type: | Barrel | Packaging Material: | Plastic | Place of Origin: | Shanghai, China |
Brand Name: | CrossQ | Model Number: | FC-P | Dimension(L*W*H): | 1000 520 1300 mm |
Weight: | 60kg | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Semi-auto Lids / Caps Pressing Machine FC-P
(With Aerofluxus Function)
(Capping Head dia340mm)
Capping Plate size: standard dia34mm, can be optional based on bigger barrel cap.
APPLICATION
This kind Lids/Caps Pressing Machine FC-P mainly used in open barrels, paint barrels, oil barrels, drums, paint bucket, hand drum (easy handheld type) series: 4L, 5L, 10L, 12L, 18L, 20L. It’s belonged to necessary special tools which widely used in Barrel, Can, Lubricants, Coatings, Chemicals, Petroleum, Edible oil and other Liquid packaging industries.
Filling Machine + Capping Machine together to meet (4-20L) Filling & Capping function.
Roller Height: 500mm (Also can be done as exact requirement)
FEATURE
1.Capping Machine FC-P: It’s an important part the production line, finishing barrel cover capping,
twice capping make sure tight & flat during and after capping.
2.Capping Machine FC-P: Locating heavy barrel below capping plate, after finishing positioning
work, use foot switch to start capping function, which including twice capping.
3.Capping Machine FC-P Aerofluxus Function: there’s an aerofluxus device under the middle size
of capping plate, this function can make barrel air-out to protect barrel when capping.
SPECIFICATION
Name | Semi-auto Capping Machine |
Model | FC-P |
Control System | Electric-Pneumatic |
Capping Range | 4-20L |
Capping Plate Size | dia34mm (Be Optional) |
Capping Speed | (20L)120-150pcs/h (4-10L)150-200pcs/h |
Material | Painted Steel, Roller without engine |
Dimension | 1000(L)×520(W)×1300(H) (mm) |
Weight | 60KG |
Another Different design:
Filling Machine + Capping Machine together to meet (4-20L) Filling & Capping function.
Roller Height: on floor
