High Quality 28w Constant Current LED Driver For Street Light
| Model No.: | AT1585 |
| Input Voltage: | AC110/220V |
| Output Power: | 7x4W/28x1W for 7 sereis 4 parallel or 28 in series |
| Power Factor: | > 0.9 |
| Certificate: | RoHS |
| Size: | Dia 67m x height 25mm |
| HS Code : | 8504109000 |
| Packing : | 1pc/PE box |
Easy to adjust the output of constant current for led lights
Export Markets : North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
The Picture of 28w LED Driver :
Specification:
Model NO. |
AT1585-28X1W |
AT1585-7X4W
|
Rated Input voltage |
110VAC/220VAC |
|
Input voltage scale |
100~240VAC ,47~63Hz |
|
Power factor |
>0.9 |
>0.9 |
Efficiency |
>80% |
>80% |
Rated input power |
<36W |
<36W |
Loading input power |
<3W |
<3W |
Short-circuit input power |
<5W |
<5W |
AC Current |
<370 mA |
<370 mA |
Cold start surge current |
<15A |
<15A |
Leakage current |
<2mA |
<2mA |
Constant current output scale |
320±20mA,56~90V |
1280±50mA,14~22.5V |
Loading voltage |
<120V |
<35V |
Ripple ,noise |
3V |
2V |
Linear adjust |
2% |
2% |
Load regulation |
2% |
2% |
Time for starting |
<1.3S |
<1.3S |
Opposite for wires |
Normal working |
|
Low or high voltage |
Low voltage ,no output or twinkle ;high voltage will damage the power supply |
|
Overheat |
IC has protection for overheat |
|
Working temp & humidity |
-20°C-60°C,20-95%RH |
|
Storing temp ,humidity |
-25°C-80°C,20-95%RH |
|
RoHS |
YES |
|
MTBF |
>25000 HOURS |
|
Dimension ,weight |
PCB:67mm*25 mm ;100g |
|
|
Input wires:
|
stranded cable/white/22AWG/length 150mm; L,N, |
|
Output wires |
stranded cables /black/22AWG/length 150mm LED - ; RED /LED + |
|
Related for 28w LED constant current Driver :
Applications:
Company Certificate & Team Training
1. About 6 years specializing in High Power LED
2. Complete supplying system with full range of Products,from high power leds ,led optical lens ,led constant drivers ,MCPCB modules and many led light components
3. Strict process and quality control
4. Good raw materials used in production
5. Strong design and production capability
6. Packaging: strong enough package to protect goods
7. Shipping: any shipping can be arranged as your request.
8. We have a R&D department with a professional team and we have a factory with rich experience, So OEM and ODM can be accepted.
9. Our after-sale service is complete. The warranty is 12 months.
How To Order Our Product ?
1,Customers offer general drawing of the product.
2,Our designer will make a professional drawing according to your product layout.
3,After your confirmation of the drawings,inform us the material and types you need.
4,We will do quote once get the confirmation of you.
5,Note Customers can order all product samples we put or you can also have your own idea as we are custom-made product supplier,so different colors and types are available.
How to contact suppliers ?
Contact Me :Marshe
Sunshine Opto-Electronics Enterprise
Skype : marshe8172
TradeManager ID: sunshineopto
Phone : +86-755-84565811
Mobile:+86-13510560547
Whats App:+86-13510560547
Send Inquiry to This Supplier
