Specifications
Constant Current Power Led Light Driver Module1.Input voltage AC100-240V
2.7S4P,28X1W
3.1.2A 14-22.5V
4.2 years warranty
28W Constant Current Power Led Light Driver Module
Main Features :
Suitable for AC100V~240V Input voltage
Output power should be less than 28W
Input and output is isolated
Power factor is > 0.9
ROHS standard
Easy to adjust the output of constant current for led lights
Specification
Model NO. |
AT1585-28X1W |
AT1585-7X4W
|
Rated Input voltage |
110VAC/220VAC |
|
Input voltage scale |
100~240VAC ,47~63Hz |
|
Power factor |
>0.9 |
>0.9 |
Efficiency |
>80% |
>80% |
Rated input power |
<36W |
<36W |
Loading input power |
<3W |
<3W |
Short-circuit input power |
<5W |
<5W |
AC Current |
<370 mA |
<370 mA |
Cold start surge current |
<15A |
<15A |
Leakage current |
<2mA |
<2mA |
Constant current output scale |
320±20mA,56~90V |
1280±50mA,14~22.5V |
Loading voltage |
<120V |
<35V |
Ripple ,noise |
3V |
2V |
Linear adjust |
2% |
2% |
Load regulation |
2% |
2% |
Time for starting |
<1.3S |
<1.3S |
Opposite for wires |
Normal working |
|
Low or high voltage |
Low voltage ,no output or twinkle ;high voltage will damage the power supply |
|
Overheat |
IC has protection for overheat |
|
|
Output power: |
7x4W/28x1W for 7 sereis 4 parallel or 28 in series | |
| Size: | Dia 67m x height 25mm | |
| HS Code : | 8504109000 | |
Packing : |
1pc/PE box |
|
Export Markets : North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Typical Application For 1.2A led Constant driver|28W Street light Driver :
1.2A led Constant driver|28W Street light Driver with Plastic enclosure :
Installing into E40 holder :
Why choosing us - SUNSHINEOPTO ?
1. About 5 years specializing in High Power LED fields
2. Complete supplying system with full range of Products,from high power leds ,led optical lens ,led constant drivers ,MCPCB modules and many led light components
3. Strict process and quality control
4. Good raw materials used in production
5. Strong design and production capability
