4 Core Single Mode 9/125 Tactical Fiber Optic Cables for Digital Camera Transmission

4 Core Single Mode 9/125 Tactical Fiber Optic Cables for Digital Camera Transmission thumbnail-1
4 Core Single Mode 9/125 Tactical Fiber Optic Cables for Digital Camera Transmission photo-1
US$ 0.1 - 5 MOQ: 1 Kilometer
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HX
Model Number:
HXYZGL
Contact Supplier Request Quote Chat Now
Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HX
Model Number HXYZGL

Specifications

4 core single mode 9/125 Tactical fiber optic cables for Digital camera transmission
Optical Fiber Cable
ISO, CE




Product Description

   1. Description

  •  HXYZGL Outdoor Aerial Optical Fiber Cable with Maximum Fiber Number of 12 Cores
  • Strength Member: FRP
  • Fiber: can choose SM 9/125 or MM: 62.5/125 ,50/125, OM1,OM2,OM3,OM4
 2. Characteristics



1. Good mechanical and environmental characteristics;

2. Flame retardant characteristics meet the requirements of relevant standards;

3. The mechanical characteristics of jacket meet the requirements of relevant standards;

4. Soft,flexible, easy to lay and splice, and with big capacity data transmission;

5. Meet various requirements of market and clients.



3. Optical Characteristics

  G.652 G.655 50/125μm 62.5/125μm
Attenuation @850nm     ≤3.0 dB/km ≤3.0 dB/km
(+20°C) @1300nm     ≤1.0 dB/km ≤1.0 dB/km
  @1310nm ≤0.36 dB/km ≤0.40 dB/km
  @1550nm ≤0.22 dB/km ≤0.23dB/km
Bandwidth (Class A) @850nm     ≥500 MHz·km ≥200 MHz·km
@1300nm     ≥1000 MHz·km ≥600 MHz·km

Fiber color code:
4 core single mode 9/125 Tactical fiber optic cables for Digital camera transmission


Note: A:The color of fiber in loose tube is arranged from NO.1 color successively.
B:Other color indentifications available on request

Cable Structure:
 4 core single mode 9/125 Tactical fiber optic cables for Digital camera transmission

4. Technical Parameters
Cable Type Fiber Count Tubes Cable Diameter Cable Weight   Tensile Strength Crush Resistance  Bending Radius
 Long/Short Term          Long/Short Term  Static /Dynamic
mm kg/km N N/100mm mm
HXYZGL-2 2 1 7.0 80 200/400 500/1000 10D/20D
HXYZGL-4 4 1 7.0 85 200/400 500/1000 10D/20D
HXYZGL-6 6 1 7.5 90 200/400 500/1000 10D/20D
HXYZGL-8 8 1 8.0 95 200/400 500/1000 10D/20D
HXYZGL-10 10 1 8.5 100 200/400 500/1000 10D/20D
HXYZGL-12 12 1 9.0 110 200/400 500/1000 10D/20D

Options

Fiber Type: G652, G655 or G657 single-mode fiber, A1a or A1b multi –mode cable, or other types of fiber;

Fiber Count: The fiber count is usually 1-6, or other contracted fiber count;

Jacket Material: Environmental thermoplastic polyurethane (TPU), or other contracted material;

Jacket Color: Black, or other contracted color.

Cable Dimension: The nominal cable dimension, or other contracted dimension;

Delivery Length: 1km or 2km, or other contracted length;

Other Requirements: Other contracted special request.



Application

1. Laying method: Duct/Aerial

2.Suitable for long-distance trunk and LAN communication

3. Fiber type: Single-mode/Multimode




Packaging & Shipping

5. Packing& Shipping



  1. packing in Wooden drums, Polywooden drums or other drums according to clients' need
  2. shipping by sea or air
4 core single mode 9/125 Tactical fiber optic cables for Digital camera transmission

Our Services

6. Services

Sample: Can provide by our factory

prist list: can provide by our salesperson

after-sales: one by one

contact:
Ms. Candy Foo
Skype: szhanxin4
Mobile: +0086-13510684370
email: fusq at


Company Information

7. Introduction



Shenzhen Hanxin Communication Optical Fiber Cable Co., Ltd is a factory who mainly produce optical fiber products:

1.Outdoor Fiber Optic Cable(GYXTW,GYFTY,GYTA,GYTS,ADSS,GYXTC8Y,GYTA53 etc.)

2.Indoor Fiber Optic Cable(Simplex/Duplex indoor cable,distribution box,break-out cable,waterproof cable etc.)

3.FTTH(bow-type access cable,self-supporting bow-type cable)

4.Fiber Patch Cord(SC,SC,LC,FC,MTRJ,MU etc.

5.Accessories:Fiber Patch Panel,Fiber Splice Closure,Fiber Media Converter,Fiber Adapter



4 core single mode 9/125 Tactical fiber optic cables for Digital camera transmission
