Help CenterSmall Wheel Loader
Related Products
Specifications
1:large or small bucket is available .2:Rated load:1000kg
3:Engine rated power :20 kw
4:Quality guaranteed for a year .
Rated load 1000Kg |
Rated bucket capacity 0.3 m3 |
Overall dimension (L×W×H) 4850×1540×2500mm |
Wheelbase 2020mm |
Wheel track 1320mm |
Min. turning radius 4200mm |
Max. climbing ability 30 ° |
Min. ground clearance 21mm |
Max. dumping angle 45 ° |
Max. dumping height 295mm |
Min. discharge distance 77mm |
Type and pressure of tyre 7.50-16;210KPa |
Max. speed 22 Km/h |
Overall weight 2350Kg |
Engine Model Changchai L28M |
Engine Power 20KW |
Rotate speed 2200r/min |
Type of cooling evaporation |
Transmission (mechanical ) 4 forward shift,2 reverseshift |
Clutch Dry single disc combined |
Brake control Hydraulic power |
