Hydraulic pile breaker Technical Specification
|
Cut piles diameter
|
BYP500S:300~550mm BYP600S:500-650mm
|
Max.Cylinder pressure
|
30MPa
|
|
Max.Hoist Capacity
|
≤300mm
|
Max.Thrust
|
320KN
|
|
Max.Cylinder required
|
20L/min
|
Machinery Tonnage
|
≥7T
|
|
Max.Oil Cylinder trip
|
200mm
|
Quantity/8h
|
100/8h
|
|
Total weight |
BYP500S:1.2T(machinery Tonnage:≥7T) BYP600S:1.8T (machinery Tonnage:≥15T)
|
||
Hydraulic pile breaker Advantages:
1.High efficiency
2.Reducing manpower
3.Low cost
4.Casting modules
5.Wireless remote control
6.Module design
7.Quick assembling connector
8.More choices of hydraulic sources
Hydraulic pile breaker Scope:
Hydraulic pile breaker can break such like cast-in-place piles, precast piles etc.It can be divided into round and square by the pile shape, widely used in high-speed railway bridges and civil building pile foundation engineering.Normally hydraulic round pile breaker can break pile diameter from 500-2200mm and hydraulic square pile breaker is suitable for square pile from 300-650mm. Our machine can meet the requirements of all kinds of large-scale infrastructure construction.
BEIYI factory is specialized in the R&D, manufacturing and sales of piling machinery and excavator attachments more than 15 years experience. With ISO9001 quality management system ;CE ; SGS Certificate .
The products cover full hydraulic pile breakers, hydraulic pulverizer,pile extractor,mechanical pulverizer , hydraulic auger drill and so on.
The company has obtained patents for pile machinery. The unique MK180S series of pile breaker (also known as pile cutter) can rapidly cut large amount of pile heads, which changed the traditional manual cutting method in China. The products have won 11 core patents, including one invention patent. At present, the pile breaker products have been exported to Myanmar, America,Australia,Indonesia, Sri Lanka, and many other countries.
Quality assurance
The warranty period is 6 months counting from the date on which the machine is delivered to the Buyer, whichever occurs first. However, for certain components and wear parts which are according to the special warranty. Within the warranty period, if any machine trouble occurs in the course of operation by reason of inferior quality, bad workmanship or the use of inferior manufacture materials, the buyer shall immediately notify BEIYI fatory in writing and provide sufficient evidences. After confirmation, TYSIM shall provide new or repaired parts at BEIYI’s expenses. However, TYSIM shall not hold the responsibility for any losses caused by misuse of the attachments, accessories, parts and components, which were not sold or approved by BEIYI fatory.
1,Are you a factory ?
Yes, we are a factory,more then 15 years factory
2,Where are your factory ?
Address: A park, ShuangMiao Industrial, HuiShan District, Wuxi, Jiangsu, China .
3, What is your delivery time?
Within one or two week or as your quantity .
4, What's your payment ?
30% deposit against the contract should be paid before the order;
70% balance should be paid off after inspection before delivery;
If you are interested in our products,please feel free to contact us!
Contact person :Jennifer.Meng
Mob:+86 18112351400
Skype:jenniferky1
wechat : meng 7463
Thank you for your attention to our product (pile breaker/cutter).
If you are interested in hydraulic pile breaker, please tell us your requirements on the construction first.Something like the pile diameter which you will break/cut, the grade of concrete, round pile or square pile, the concrete reinforcement arrangement.
When we know all about your requirements and conditions, we will introduce the most suitable products to you.
