Turn-Key Tower Rice Paddy Corn Grain Dryer Machine
SRON Concentrates On Grain Drying Tower System |
- Draftsman of China Grain Dyer Standard.
- SNHT series forth and reflux drying tower,commonly used in large-scale grain storage project. Applys to variety grain high-quality drying, such as paddy rice, sorghum, soybeans, corn and wheat etc.
- Tiny grain dryer, usually used for drying high moisture paddy rice, wheat, corn, soybeans and other grains. Apply to farm, grain supply center etc. (tower grain dryer)
SRON SNHT Series Forth and Reflux Grain Drying Tower Specifications |
1. Drying Stage
- In the top drying stage , high-heat air made grain rapid warming, and took away part of granule surface moisture;
- Medium-heat stage takes away large amounts of moisture with medium heated air;
- After high-heat and medium-heat stage, the grain granule temperature has raised, so bottom drying stage use low-heat air. Low-heat air can easily take away stronger grain inside moisture but avoid grain temperature too high.
- At last, dried grain come to cooling stage, after enough cooling, grain with safety moisture and temperature can comes to silo storage directly. (tower grain dryer)
- Mechanized continuous operation, stable performance, easy to operate, saving land construction
- Strong adaptability, can take into varieties of grain drying.
- Complete and uniform drying kinds of grain , dried grain can comes to silo directly.
- Dried grain is in high quality, no cracking, no burned, no broken, no pollution etc.
- Patent design of discharging ensures no grain residue,and can be controlled and adjusted the discharging speed.
- Original dedusting technology for exhaust gas collecting and processing, environment friendly. (tower grain dryer)
Model | SNHT100 | SNHT150 | SNHT200 | SNHT250 | SNHT300 | SNHT400 | SNHT500 |
Capacity (t/d) | 100 | 150 | 200 | 250 | 300 | 400 | 500 |
Moisture Expected Lowed Down(%) |
4-16 | ||||||
Heated Media | Cleaning Air | ||||||
Heated Air Temperature(°C) |
<120 | ||||||
Drying Evenness(%) |
>98 | ||||||
Broken Rate(%) | <0.5 | ||||||
Unit Heat Consumption (kj/kg H2O) |
5800 | ||||||
Coal Consumption (Standard)(kg/h) | 60-230 | 90-345 | 120-460 | 150-575 | 180-690 | 240-1000 | 300-1380 |
Installation Capacity | According to the environment, conditions, expected moisture lowed down and configuration. | ||||||
Dryer Size(M) | 4×3 | 4×3 | 5×3.2 | 5.5×3.2 | 5.5×4 | 5.5×4.5 | 6×6 |
Dryer Height(M) | 6-12 | 8-15 | 13-17.5 | 14-18 | 14-19 | 15-20 | 16-22 |
SRON Tiny Grain Drying System Specifications |
1. Application and Features
- Used for drying high moisture paddy rice, wheat, corn, soybeans and other grains. Apply to farm, grain supply center etc.
- Use heated cleaning air as medium, grain was heated evenly and is in high quality after drying.
- Coal or straw as fuel and converted to cleaning heat air, no pollution for grain.
- The dryer is simple, low investment, low operating cost, easy to operate, easy to maintain. (tower grain dryer)
Model |
Capacity (t/d) | Heat Consumption (MW) |
Dryer Size |
Dryer Height(M) | Moisture Lowed Down (%) |
Heated Media |
WGHX30 | 30 | 0.15-0.35 |
4×2.5 | 5-7 |
3-10 |
Cleaning Air |
WGHX50 | 50 | 0.25-0.6 | 6-8 | |||
WGHX100 | 100 | 0.5-1.2 | 7-12 | |||
WGHX150 | 150 | 0.75-1.8 | 9-15 |
Part of Respected Grain Drying System Customers, Your Join is Warmly Expected |
Email SRON, Get Professional Grain Drying Systems Solution Immediately!
Contact: Hilda Wan
Tel/APP: 0086-15827569971
Skype: sronsilo08 AT
Email: hilda.wan AT
(Turn-Key Tower Rice Paddy Corn Grain Dryer Machine)
