KOSOO DR 1 Inch Flexible and Flame-retardant Elastomer Heat Shrink Tube in Mexico

KOSOO DR 1 Inch Flexible and Flame-retardant Elastomer Heat Shrink Tube in Mexico thumbnail-1
KOSOO DR 1 Inch Flexible and Flame-retardant Elastomer Heat Shrink Tube in Mexico photo-1
US$ 0.01 - 1 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KOSOO
Model Number:
DR
Contact Supplier Request Quote Chat Now
Guangzhou Kaiheng K&S Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KOSOO
Model Number DR
Type Insulation Sleeving
Material Other
Application Low Voltage
Rated Voltage 11KV
Tensile Strength 10.4MPa
Product Description



KOSOO DR

Diesel-resistant, flexible, flame-retardant elastomer tubing





With resistance to aviation and diesel fuels, hydraulic fluids, and lubricating oils, KOOSOO DR is ideal for applications require resistance to fuels, fluids and solvents. It is particularly suitable for protecting and bundling of high-performance cables and wiring harnesses.



Features



Features/Benefits



·Shrink ratio: 2:1

·Outstanding fluid and heat resistance.

·Abrasion resistance and excellent mechanical properties.

·Flexible, flame-retardant.

·Free of PCBs, PCPs, polybrominated biphenyls (PBBs), polybrominated biphenyl oxides and ethers (PBBOs, PBBEs and PBDEs) and toxic heavy metal compounds, which are classified as environmentally hazardous substances. Conform to European RoHS environmental directive.





Operating Temperature Range



·

Operating temperature range: -75℃~150℃



·Minimum full recovery temperature: 175℃





Specifications/Standards





AMS-DTL-23053/16





Advantages



Specification values



Property

Requirement

Test method

Typical value

Physical:

Tensile strength

11.7MPa min.

ASTM D 638

≥14MPa

Elongation

250% min.

ASTM D 638

≥350%

Heat shock  250℃, 4hrs

No cracking, dripping or flowing

ASTM D 2671

Pass

Low temperature flexibility -75℃,  4hrs

No cracking

ASTM D 2671

Pass

Aging   150℃, 168hrs

Tensile strength after aging

10.3MPa min.

ASTM D 638

≥12MPa

Elongation after aging

200% min.

ASTM D 638

≥300%

Electrical:

Dielectric voltage withstand

2500V,60sec,no breakdown

ASTM D 2671

Pass

Dielectric strength

11.9KV/mm min.

ASTM D 2671

≥11.9KV/mm

Volume resistivity

109Ω·cm min.

ASTM D 876

≥109Ω·.cm

Chemical:

Corrosion

No corrosion

ASTM D 2671

Pass



Flammability

Self extinguishing within 1 minute

ASTM D 2671

Pass

Fluid resistance:

23℃,24hrs (aviation and diesel fuels, hydraulic fluids, lubricating oils, etc.)



Tensile strength

10.4MPa min.

ASTM D 2671

≥12MPa

Elongation

200% min.

ASTM D 2671

≥300%

Dielectric strength

7.9KV/mm min.

ASTM D 2671

≥9.0KV/mm



Product Sizes



mm/inch



Size

Inside diameter

Wall thickness

Standard length

(m/spool)

As supplied(min.)

After recovery(max.)

After recovery

1/8

3.2(0.125)

1.6(0.062)

0.76±0.15(0.030±0.006)

100

3/16

4.8(0.187)

2.4(0.093)

0.84±0.15(0.033±0.006)

100

1/4

6.4(0.250)

3.2(0.125)

0.89±0.15(0.035±0.006)

100

3/8

9.5(0.375)

4.8(0.187)

1.02±0.20(0.040±0.008)

50

1/2

12.7(0.500)

6.4(0.250)

1.22±0.20(0.048±0.008)

30

3/4

19.1(0.750)

9.5(0.375)

1.45±0.28(0.057±0.011)

30

1

25.4(1.000)

12.7(0.500)

1.78±0.28(0.070±0.011)

30

1 1/2

38.1(1.500)

19.0(0.750)

2.41±0.41(0.095±0.016)

15

2

50.8(2.000)

25.4(1.000)

2.79±0.41(0.110±0.016)

22

 KOSOO DR 1 inch flexible and flame-retardant elastomer heat shrink tube in Mexico

Packaging & Shipping



 Ordering Information

Color

Standard: Black (-BK)

Nonstandard colors can be available upon request.

Nonstandard size

Nonstandard sizes are available upon request.

Standard packaging

On spools.

Ordering description

Specify product type, size (mm or inch) and color.
