Here We Are Not Able To Present All Technical Details of Our 30ton-5000ton Powder Storage Silo, SRON Worth Your Click CONTACT US for thorough Technoloy Information. Thank you!
SRON Powder Storage Silo Specifications
| 1.What Are Features of SRON 60t Powder Storage Silo ? |
1.SRON’s latest model cement silo used for concrete batching plant is specially designed for export. It is with features of high adaptation for long-distance container loading transportation, delivery cost saving, easy and fast on-site assembly and move and high safety etc.
2.SRON’s export cement silo has strong supporting adaptability. It can be customized designed and manufactured according to the model and height needs of the concrete batching plant and the screw conveyor.
3.SRON is professional manufacturer on cement silo in China, and is fixed cement silo production company for China top concrete batching plant companies like Zhengzhou Shuigong, SANY, Zoomlion etc. We sincerely wish for long term cooperation with international users and traders.
| 2.Main Models & Technical Parameters of SRON Powder Storage Silo |
| You Can Click on It → |
SRON 30T |
SRON 50T |
SRON 60T |
SRON 80T |
SRON 100T |
SRON 150T |
SRON 200T |
SRON 300T |
SRON 500T |
| Silo Diameter | 3.0m |
3.0m | 3.0m | 3.0m | 3.0m | 3.3m | 4.5m | 4.5m | 6.0m |
| Silo Height | 4.8m |
5.7m | 7.1m | 9.5m | 12.0m | 24.7m | 19.5m | 25.8m | 23.3m |
| Total Silo Height | 11.4m |
12.0m | 13.4m | 15.6m | 18.0m | 29.0m | 25.2m | 29.5m | 28.8m |
| Type | Welded Whole | Bolt Assemble | |||||||
| Usage | For Concrete Batching Plant | ||||||||
| Configuration | Standard |
De-dusting system, explosive-proof valve, valve, cement block breaker device, stairs, handrail, maintenance platform, cement loading pipe. |
|||||||
| Optional |
Electrical deduster, level indicator, loading filter device and vibrator |
||||||||
| NOTE | The anti-explosive valve is dual-direction pressure adjustement function to assure safety;The block breaker device can assure smooth unloading of cement in silo. | ||||||||
| 3.Strict Materials Usage Guarantees High Quality of 60t Powder Storage Silo |
1.Raw Materials. The silo body steel plate and support leg steel are all of national standard and from famous steel factory.
2.Core Parameters of Steel Plate Thickness, Weight and Useful Volume of SRON Cement Silo.
| 60T Cement Silo | 80T Cement Silo | 100T Cement Silo | ||||
| Brand | SRON | Ordinary | SRON | Ordinary | SRON | Ordinary |
| Body Thickness | 3.0-4.0-5.5(mm) | 2.5-3.5-4.9(mm) | 3.5-4.5-6.5(mm) | 3.0-4.0-5.0(mm) | 3.5-4.5-6.5(mm) | 3.0-4.0-5.0(mm) |
| Support Leg | φ219*3.67mm | φ219*3.0mm | φ219*4.25mm | φ219*3.67mm | φ219*4.25mm | φ219*3.67mm |
| Weight | 3.8t | 3.0t | 5.7t | 4.5t | 6.0t | 4.8t |
| Useful Volume | ≥48m3 | ≤44m3 | ≥65m3 | ≤58m3 | ≥83m3 | ≤73m3 |
| 4.Surface Treatment Technology Guarantees Durability of 60t Powder Storage Silo |
1.We apply hand-polishing + one time coat painting + two times surface painting + high quality paint. Compared with normal surface treatment, ours can strictly protect the silo body from corrosion thus to longer the cement silo life span.
2.Painting. The logo, color or other pictures can be appointed by the Buyer for free.
3.The main parts is painted with matching words like 1,2,3…. to facilitate on-site assembly work.
| 5.WHY SRON Can Save Your Delivery Cost? |
1.SRON is with rich export container loading experience. We will arrange the best solution to save the container usage.
2.We will consider your other goods situations and max use the space.
3.We will extra put more 2 sets of spareparts like bracing for back-up in case of lost.
| 6.Which Details Guarantee The Successful Assembly of 60t Powder Storage Silo ? |
1.SRON will provide glue-gun, installation tools for free to assure the on-site smooth work.
2.Delivery with rich screw and sealing glue. The screw is national standard high quality product and the glue is china famous brand with assurance of strict sealing.
3.Furnish with detailed installation drawing and manual and timely response for any technical support. Normally the users can effectively and successful install well the silos by themselves and thus save the cost of inviting our technician to site.
4.If needed, SRON can provide overseas on-site assembly service.
| 7.Part Cases of SRON Powder Storage Silo |
| 8.Our 360 Degree Service for 60t Powder Storage Silo |
Technology & Detail Determine Your Success or Failure.
Contact Now! Get More Details And Discount Policy For 60t Powder Storage Silo !
