3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube

3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube thumbnail-1
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube thumbnail-2
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube thumbnail-3
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube thumbnail-4
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube thumbnail-5
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube photo-1
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube photo-2
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube photo-3
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube photo-4
3/4 Inch Semi-rigid Kynar Heat Shrink Clear Tube photo-5
US$ 0.015 - 1.2 MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KOSOO
Model Number:
Kynar
Contact Supplier Request Quote Chat Now
Guangzhou Kaiheng K&S Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KOSOO
Model Number Kynar
Type Insulation Sleeving
Material Other, Fluoropolymer
Application Low Voltage
Rated Voltage 600V
Tensile Strength ≥35MPa

Kynar Heat shrink clear tube



Application

KOSOO Kynar has outstanding abrasion resistance, cut-through resistance, chemical and solvent resistance and high-temperature performance. It is especially suitable for applications requiring high-temperature performance. It is also used for insulation and strain relief of soldered joints, identification and inspection of covered components.



 Features/Benefits

·Shrink ratio: 2:1.

·Tough, semi-rigid, thin-wall insulation.

·High flame-resistance; high-temperature performance.

·Outstanding chemical and solvent resistance.

·Conform to European RoHS2002/95/EC environmental directive.



 Operating Temperature Range

·Operating temperature range: -55~175 degree Celsius

·Minimum shrink temperature: 155

·Minimum full recovery temperature: 175

 3/4 inch semi-rigid Kynar Heat shrink clear tube3/4 inch semi-rigid Kynar Heat shrink clear tube

 Specifications/Standards

UL224 150 600V VW-1

AMS-DTL-23053/8



n        Specification values



Property

Requirement

Test method

Typical value

Physical

Tensile strength

34.5MPa min.

ASTM D 638

≥35MPa

Elongation

150% min.

ASTM D 638

≥200%

Heat shock

 300, 4hrs

No cracking, dripping or flowing

ASTM D 2671

Pass

Low temperature flexibility

 -55, 4hrs

No cracking

ASTM D 2671

Pass

Aging  250,168hrs







Elongation after aging

50%

ASTM D 638

≥50%

Electrical

Dielectric voltage withstand

2500V,60sec,

no breakdown

ASTM D 2671

Pass

Volume resistivity

1013Ω·cm min.

ASTM D 876

≥1013Ω·cm

Chemical

Corrosion

No corrosion

ASTM D 2671

Pass



Flammability

VW-1

UL224

Pass



n        Product                                                       mm/inch

Size

Inside diameter

Wall thickness

Standard length

 As supplied (min.)

 After recovery (max.)

After recovery

3/64

1.20.046

0.60.023

0.25±0.050.010±0.002

1.2

1/16

1.60.063

0.80.031

0.25±0.050.010±0.002

1.2

3/32

2.40.093

1.20.046

0.25±0.050.010±0.002

1.2

1/8

3.20.125

1.60.063

0.25±0.050.010±0.002

1.2

3/16

4.80.187

2.40.093

0.25±0.050.010±0.002

1.2

1/4

6.40.250

3.20.125

0.30±0.080.012±0.003

1.2

3/8

9.50.375

4.80.187

0.30±0.080.012±0.003

1.2

1/2

12.70.500

6.40.250

0.30±0.080.012±0.003

1.2

3/4

19.10.750

9.50.375

0.43±0.080.017±0.003

1.2

1

25.41.000

12.70.500

0.48±0.080.019±0.003

1.2

1 1/2

38.11.500

19.10.750

0.51±0.080.020±0.003

1.2

2

50.82.000

25.41.000

0.58±0.080.023±0.003

1.2

 3/4 inch semi-rigid Kynar Heat shrink clear tube

3/4 inch semi-rigid Kynar Heat shrink clear tube3/4 inch semi-rigid Kynar Heat shrink clear tube3/4 inch semi-rigid Kynar Heat shrink clear tube

 Ordering information

Color

Standard: clear (-CL)

Nonstandard colors can be available upon request.

Nonstandard size

Nonstandard sizes are available upon request.

Standard packaging

1.22m /length

Ordering description

Specify product type, size (mm or inch) and color.



3/4 inch semi-rigid Kynar Heat shrink clear tube
