Specifications
1.8-Port Gigabit ethernet switch2.8 port 10/100/1000Mbps TX Auto-Negotiation
3.Factory price
4.FCC,CE
8-Port Gigabit ethernet switch
JGS-108R
JGS-108R 8-Port Gigabit ethernet switch is an Ethernet Switch with good quality and very favourable price. OEM service in large quantity is offered.
Product description
Specification
Characters
1.Compliant with the IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX ,IEEE 802.3ab 1000Base-T specifications
2.8 port 10/100/1000Mbps TX Auto-Negotiation Ethernet Switch
3.Auto negotiation of speed (10/100/1000Mbps), and duplex mode. Note that 1000Mbps supports only full duplex mode
4.Automatic Source MAC Address Learning and Aging
5.IEEE 802.3x flow control for Full-duplex
6.Back Pressure function for 10/100Mbps Half-duplex operation
7.Plug and Play
Spec
Standard |
IEEE 802.3 10Base-T,IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T IEEE 802.3x Flow Control |
Port |
8 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media |
10BASE-T : UTP Cat.3 or up 100BASE-TX/1000Base-T : UTP Cat.5 or up |
Transmission Method |
Store and Forward |
Data Transfer Rate |
10/100M (Half-duplex) 10/100M /1000Mbps(Full-duplex) |
Access Method |
CSMA/CD |
LED Indicators |
Power, Link/Act |
Environment |
Operating Temperature: 0°C~40°C Storage Temperature: -40°C~70°C Operating Humidity: 10%~90%RH(non-condensing) Storage Humidity: 5%~90%RH(non-condensing) |
Power |
5V/2A |
Dimensions |
178mmx117mmx25mm |
Safety & Emission |
FCC, CE |
Workshop
PCB test
Quality and warranty
All our products are checked quality passed before delivery. Besides we provide ONE YEAR WARANTY for defective items if any.
