6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw

6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw thumbnail-1
6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw thumbnail-2
6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw thumbnail-3
6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw photo-1
6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw photo-2
6-7.5m Bus Air Conditioner System With Cooling Capacity 15Kw photo-3
US$ 399 - 1,999 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Yuxin
Model Number:
KT-15
Contact Supplier Request Quote Chat Now
Zhengzhou Hangyuan Refrigeration Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin/Qingdao/Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Yuxin
Model Number KT-15
Size 2170*1580*177mm, 2170*1580*177mm
Type Other, Bus Air Conditioner System, 15kw bus air conditioner
Car Make Bus/Coach/Van/Vehicle
OE NO. 2011040602



  • The shell material is fiber glass structure,uviofast and firm.
  • With high eddicient internal thread copper pipe evaporator.
  • Automatic protection functions to make the whole system stable and reliable.
  • Unibody design,compact structure.
  • Environmentally friendly.
6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw
6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw

Technical Data

Model KT-15
Applicable for 6-7.5m bus
Type Vehicle Engine Driven
Structure Rooftop Mounted
Cooling Capacity 15Kw/51150BTU
Voltage 12/24V
Compressor PLM-32/DKS-32
Condenser Fan 2PCS
Coil Type Copper tube&Aluminum fin
Air Flow 3800m³/h
Evaporator Blower 4PCS
Coil Type Copper tube&Aluminum fin
Air Flow 3200m³/h
Refrigerant R134a
Dimension 2170×1580×177mm

Compressor & Fans

6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw

6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw

 6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw

Packaging & Shipping

 6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw



Company Information



1.The company follows the quality policy Quality first,Users first,Continuous improvement,aims for zero product defect,and has got ISO9001,ISO/TS16949 quality management system certificates and ISO14001 environment management system certificate.

2.We are eager to achieve the perfect combination of system control and equipment protection,as well as the harmonious development of enterprise and environment.



Our Services

Pre-sale service

    Following Yuxin specification for automatic air conditioner application,our factory project engineers and technical staff from passenger vehicel factories work together to study the vehicle usage,design the most appropriate air-conditioner,provide complete technical information for the corresponding installation and usage

Sale service

   Provide installation User Manual and technical Support to complete the installation

After-sale service

   If any faults in using time,you can contact us,and our technicist will supply the solution in time for you,just use our bus air conditioner freely.



6-7.5m Bus Air Conditioner System with Cooling Capacity 15Kw
