Instant Video Measuring Machine IM150

Instant Video Measuring Machine IM150 photo-1
Instant Video Measuring Machine IM150 photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JATEN
Model Number:
IM150
Payment & Shipping
Payment Methods:
Port of Shipment:
any port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name JATEN
Model Number IM150



Description:

New Generation Measuring Instrument

Accurate quick measurement by pressing one key, 2 Seconds for all measuring.

Quick speed, high efficiency, fit for batch measurement

Easy to use. The whole measuring process could be finished with result output just pressing one key

Automatic image registration, no need to fix workpieces, no need of carriers

Multi workpieces could be measured at the same time with result output

Measuring result could be output in Word, Excel.

The platform does not need to move during measuring process

Outer connectors are allocated which could be customized onto kinds of production lines to achieve quick on-line measurement





Application:



batch measurement for gear,Screw etc. Mobile Jacket,glass and some small measuring pieces



Specification:







Model

IM60

IM100

IM150

Measuring Range

62X46 mm

96x72mm

142x96mm

Max Working Height

200mm

100mm

200mm

Dimensions

550X400X895mm

500X500X1000mm

460X20X1440mm

Image Sensor

1/1.8’’ , 5 Mega-pixel CCD

2/3’’ , 5 Mega-pixel CCD

2/3’’ , 5 Mega-pixel CCD

Lens

Double Telecentric Lens

Double Telecentric Lens

Double Telecentric Lens

Measuring Volume

50mm

50mm

50mm

Repeatability

2 um

2 um

2 um

Measuring Accuracy

10 um

10 um

10 um

Output

OK/NG/FAIL

OK/NG/FAIL

OK/NG/FAIL

Interface

USB2.0 Series A

USB2.0 Series A

USB2.0 Series A

Memory

>300GB

>300GB

>300GB

Illumination

LED

LED

LED

Z-axis

Movement Range:30mm   Max Loading:10kg

Power

220V/50HZ , 110V/60HZ
