Description:
l Be Applied to Mechanical ,,Electronic ,Plastic Fields etc.
l Function of Data Processing,Displaying,Input,Output,
l With RS-232 Interface
l With Quick Measuring Software
l Obviously assistant laser position system
l UK Renishaw Probe
Specifications:
Model | VMS-1510T | VMS-2010T | VMS-2515T | VMS-3020T | VMS-4030T |
Metal Table Size(mm) | 354X228 | 404X228 | 450X280 | 506X356 | 606X466 |
Glass Table Size(mm) | 210X160 | 260X160 | 306X196 | 350X280 | 450X350 |
X,Y-axis Travel(mm) | 150X100 | 200X100 | 250X150 | 300X200 | 400X300 |
Z-axis Travel(mm) | 200 | 200 | 200 | 200 | 300 |
Resolution(mm) | 0.0005 | 0.0005 | 0.0005 | 0.0005 | 0.0005 |
X,Y-axis Accuracy(um) | ≤3+L/200 | ≤3+L/200 | ≤3+L/200 | ≤3+L/200 | ≤3+L/200 |
Measuring Software | Standard | Standard | Standard | Standard | Standard |
Net Weight(kg) | 100 | 110 | 120 | 200 | 240 |
Dimensios(mm) | 600x530x950 | 600x550x920 | 690x550x1020 | 780x600x1060 | 945x646x1096 |
Video System | 1/3“ Color CCD Camera , 0.7~4.5 Zoom Lens, Video Total Magnification:30X~230X , Object View:7~1.1mm LED adjustable Light Source | ||||
Probe | UK Renishaw Probe | ||||
Power | 180V~260V(AC),50HZ | ||||
Packing list:
Packing List | Packing List | Packing List |
Quick Measuring Software | CCD Camera | Zoom lens 0.7~4.5X |
Calibration Block | Capture Card | LED Light Source |
Power,AV,RS232 Cable | Scale Transfer | Dell PC System |
Optional Items:
Optional Items | Optional Items | Optional Items |
Digital Read Out DP100 | Navitar Click Zoom lens | Rotary Table |
Digital Read Out DP300 | Navitar Coaxial Zom Lens | Rotary Table |
Foot-Switch | Sony CCD Camera | Working Cupboard |
