1000KN Computer Control Electro Hydraulic Servo Steel Strand Testing Machine / Steel Strand Tester / Universal Testing Machine
Electro hydraulic servo steel strand test machine is dedicated to test the mechanical properties of pre-stressed steel strand. The machine is equipped with Lenovo computers, HP printers, large gauge electronic extensometers; optical encoder, and full-featured general-purpose test software, users can easily finish the test. Besides, the specialized steel strand extension jaw can ensure fracture in the sample middle; further improve the test success rate. You can check and print test results (force - displacement, force - deformation, stress - displacement, stress - deformation, force - time, deformation - time) six curve and related test data with the software self-test function that can self-diagnose problems(for details, please refer to software instructions). This machine can test strand tensile strength, non-proportional extension strength, elastic modulus, elongation and other mechanical properties.
It is widely used in industrial and mining enterprises, research institutes, universities, engineering quality supervision station and other departments.
Technical parameters:
1. Max load: 1000kN
2. Test Force showed the relative error: ≤±1% indicating value
3. Test Force Resolution: 0.01kN
4. Displacement measurement resolution: 0.01mm
5. Deformation measurement accuracy: 0.01mm
6. Maximum tensile test space: 1000mm
7. Compression space: 600mm
8. Piston stroke: 150mm
9. Clamping diameter of round sample: 15.20mm(or other specifications )
10. Upper and lower compress plates size: φ160mm
11. Distance Between Two Column: 450 mm
12. Maximum move speed of piston: 50mm/min
13. Clamping method: Automatic clamping
14. Host machine outside size: 890×660×2500 mm
15. Weight: 3500kg
1.Outside packeg: standard export wooden case
2. Inside package: strength film
3. Special packages: according to buyer's requirements
4. The packages suitable for international transport by sea, by air or any other delivery methods
