GM2, P Series , Light Curtain ,Elevator Light Curtain

GM2, P Series , Light Curtain ,Elevator Light Curtain thumbnail-1
GM2, P Series , Light Curtain ,Elevator Light Curtain photo-1
US$ 1 - 1,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
ES
Model Number:
GM2
Contact Supplier Request Quote Chat Now
ES (Nanjing) Escalator Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name ES
Model Number GM2
 GM2, P Series , Light Curtain ,Elevator Light CurtainGM2, P Series , Light Curtain ,Elevator Light Curtain

Product Description
Specification Model
192P (V) 320PG (V) 384P (V) 640PG (V)
No. of diodes 64 64 128 128
Max. beams 192 320 384 640
Min. beams 192 192 384 384
Distance between Two Diodes emitter/ receiver 42/ 55 mm emitter/ receiver 13/ 27 mm
Size 1980 height x 30 width x 9/16/35 thickness mm
Hitachi/ Mitsubishi/ Toshiba 2 in 1 light curtain available
Light curtain Detecting Distance 0~4.5 meters     Customized to reach 20 meter
Light-proof can work under the sunlight ≥100,000 lux
Installation Tolerance Vertical ≤±20mm, horizontal ≤± 10mm, angle ≤±7°
Working Temperature -25°C~+65°C
IP Ip33 circuit strip    Ip63 controller box
Response Time ≤80 ms
Cable Strength 3C, 4.5M*2, 1 million times of life
EMC En61000 GB/T17626
Timeout Response 25±5s Buzzer rouse
Power ≤7.5 VA
Voltage Range 85~264VAC 60/50Hz
