Home > Industrial Equipment & Components > Cleaning Machine > Abrator > Kaitech Sand Suction Machine

Kaitech Sand Suction Machine

Name: Kaitech Sand Suction Machine
Brand: Kaitech
SKU: 106552495
Availability: InStock

Kaitech Sand Suction Machine thumbnail-1

Kaitech Sand Suction Machine thumbnail-2

Kaitech Sand Suction Machine thumbnail-3

Kaitech Sand Suction Machine thumbnail-4

Kaitech Sand Suction Machine thumbnail-5

Kaitech Sand Suction Machine thumbnail-6

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Kaitech

Contact Supplier Request Quote Chat Now

Shandong Kaitai Shot Blasting Machinery Share Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shandong, China

Brand Name Kaitech

Model Number VR30-VR132

Feature Other

Fuel Electric

Certification CE

Use Burnishing, Deflashing

Cleaning Process Other, abrasive

Cleaning Type High Pressure Cleaner

Industry Used Other

Material Metal / Coil

Power(W) Cusomized

Dimension(L*W*H) Customized

After-sales Service Provided Engineers available to service machinery overseas

Kaitech Sand suction machine

Product Description

1.Brand advantage:

Each set of vacuum sand system researched and designed by Shandong kaitai is made of suction tool, suction hose, bunker,vacuum pump,motor of main components.The system, equipped with electric cabinet, has strong Structure and a strongmaintenance door, including the back pulse cleaning system (equipped a safety valve and automatic order filtering unit), motor chamber (accommodated motor and the vacuum pump with complete sets of exhaust muffler).

Shandong kaitai series vacuum sand equipment includes a variety of units to suit all applications. Maximum power unit is 120 kW, but small unit can also choose 7.5 kW.Shandong kaitai sand vacuum system is designed to meet current environmental regulations. Vacuum sand vacuum systemcan clear any remaining dust and abrasive particles from the workpiece surface, achieving the high specification of the international standard for surface treatment.

2.The specifications of Sand suction machine

3.VR series vacuum sand machine introduction:

Conventional abrasive recycling method is expensive and timeconsuming. Vacuum suction sand machine is one of the most efficient and most economical and most effective cleaning method. The design of this device has the characteristics such as small structure, easy operation, easy maintenance, high efficiency,which can full-quality complete the task.

4.Main functions:

Recovery of abrasives in the cabin, oil tank, or dry ground saved in the process of sand blasting and abrasives used for cleaning and hull section in the complex artifacts.

5.Design principle:

Based on the pneumatic conveying system, which uses high speed air flowing, sand suction tube with wear-resisting will convey abrasive from the workplace to the reservoir sand bucket, with easy recycling.

6.Product features:

Compared with system cleaning method, it has higher productivity.

As there is no mechanical moving on the abrasive recycling line, it reduces the failure rate.

Processed surface can come into the spray process in a timely manner.

7.Using Process:

Abvr series vacuum recovery system is designed to recover spent dry recyclable abrasivefrom a blasting

Area into a silo for subseqyent return to the blast cleaning equippment or in the case of expendable abasives,for disposal into a waste hopper.

After depositing the abrasve into the silo,the vacuum flow containing air and dust continues on to the suction unit,where the dust particies in this stream are removed by high performance filter cartridges prior to exhausting sir to atomsphere.

The VRS is of strong construction with sturdy maintenance access doors and contains the filter section fitterd wit safety relief value and automaized sequenced reverse pulsejet and filter cleaning machine system,motor compartment housing an elextrics drive motor and a vacuum pump competlet with exhaust silencer.this unit is also fitter with an electrics control panel.

The vrs id designed to meet present and proposed environmental.Dust emission.

Trade information

MOQ: 1set.

Settlement Currency: USD, RMB, EUR.

Trade mode: EXW,FOB ,CFR, CIF.

Payment term: 30% deposit by T/T, the balance paid before delivery or L/C at sight.

Delivery time: Within 20-60 days according to different type equipment.

Shandong Kaitai Dehumidifiers are delivered as a complete unit with fans, filters, rotor and controls. The dehumidifier is ready for site installation and connection to standard-size ducting.

Each dehumidifier will be custom designed according to the local conditions and the needs of the customer.

Our Services

1.Reply your inquiry in 24 hours.

2.Experienced staffs answer all your questions in time.

3.Customized design is available.

4.Exclusive and unique solution can be provided to our customer by our professional engineers and staff.

5.Special discount and protection of sales are provided to our distributor.

6.We are professional manufacturer of shot blasting Machine. Have a professional design team with more than 10 years de sign experience engineers, competitive with good quality

7.As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature.

8.Prompt delivery, site installation and commissioning.
